ULN2803ADWR
Eight-channel NPN Darlington array for high-voltage, high-current applications. Features a 50V collector-emitter breakdown voltage and a 500mA maximum collector current per channel. Designed for surface mounting in an 18-SOIC package, operating from -40°C to 85°C. This AEC-Q100 qualified component offers lead-free and RoHS compliant construction.
Similar Components
CD4051BM96
16-pin SOIC analog multiplexer, featuring an 8:1 channel configuration and logic-level conversion. Operates across a wide supply voltage range from 3V to 20V, with a maximum input voltage of 20.5V and a minimum of -0.5V. This component supports a broad operating temperature range of -55°C to 125°C, suitable for military applications. The device offers a single function with dual terminal positioning and a JEDEC package code of R-PDSO-G16.
CD4071BE
CMOS OR Gate IC, 4-Element, 2-IN, 14-Pin PDIP
OPA333AIDBVT
Precision zero-drift CMOS operational amplifier featuring a 350kHz bandwidth and 17µA operating supply current. This single-channel op amp offers a low input offset voltage of 10µV and high CMRR of 106dB, operating from a minimum supply voltage of 1.8V up to 5.5V. Designed for precision applications, it boasts a 120dB PSRR and a 0.16V/µs slew rate, packaged in a compact SOT-23 for efficient integration.
LMC555
Single timer IC, surface mount, MSOP package. Features a 3MHz frequency, 1.5V to 15V supply voltage range, and 150µA operating supply current. Offers 100mA output current with a 100ns propagation delay and turn-on delay time. Operates from -40°C to 125°C with 555mW power dissipation. RoHS compliant and lead-free.
NE5534
Low-noise operational amplifier featuring a 10MHz bandwidth and 13V/µs slew rate. This general-purpose, bipolar amplifier offers a 100dB voltage gain and a 38mA output current. Designed for dual supply operation from ±5V to ±15V, it boasts a 70dB common-mode rejection ratio and a 500µV input offset voltage. Packaged in an 8-SOIC case, this RoHS compliant component operates within a 0°C to 70°C temperature range.
CD4049
6-channel CMOS buffer/inverter IC, operating from 3V to 18V, features 6 independent inverting logic gates. This surface-mount device in a 16-SOIC package offers a high level output current of -5.2mA and a low level output current of 4.3mA. With a propagation delay of 50ns and a quiescent current of 4uA, it supports a wide operating temperature range of -55°C to 125°C. The component is lead-free, RoHS compliant, and utilizes gold contact plating.
About ULN2803ADWR
The Texas Instruments ULN2803ADWR Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Eight-channel NPN Darlington array for high-voltage, high-current applications. Features a 50V collector-emitter breakdown voltage and a 500mA maximum collector current per channel. Designed for surface mounting in an 18-SOIC package, operating from -40°C to 85°C. This AEC-Q100 qualified component offers lead-free and RoHS compliant construction.. Key parameters include Collector Emitter Breakdown Voltage: 50V, Collector-emitter Voltage-Max: 1.6V, Current Rating: 500mA, DC Rated Voltage: 50V, and Height: 2.35mm. ULN2803ADWR is manufactured by Texas Instruments as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
