TPA2005D1DGNR
Mono Class-D audio amplifier delivering 1.4W output power into an 8 Ohm load. Features a wide operating voltage range of 2.5V to 5.5V and a low quiescent current of 2.8mA. Operates efficiently across a temperature range of -40°C to 85°C. Packaged in a compact HTSSOP EP with dimensions of 3mm x 3mm x 1.1mm, this lead-free component is supplied on tape and reel.
Similar Components
CD4060BM
CMOS 14-Stage Counter/Divider u0026 Oscillator, 24MHz, 18V, 16-SOIC
CD4081
CMOS logic IC featuring four independent 2-input AND gates. Operates with supply voltages from 3V to 18V, offering a maximum output current of 6.8mA. This through-hole mounted component, packaged in a 14-pin PDIP, boasts a propagation delay of 90ns and a turn-on delay time of 12ns. With a wide operating temperature range of -55°C to 125°C, it is RoHS compliant and constructed with a plastic package body.
TL072CP
Dual JFET operational amplifier featuring a 3MHz gain bandwidth product and 13V/µs slew rate. This general-purpose amplifier offers a 70dB common mode rejection ratio and operates with dual supply voltages from 3.5V to 18V. The component boasts low input bias current of 200pA and an input offset voltage of 3mV. Packaged in an 8-pin DIP, this RoHS compliant IC is suitable for a wide temperature range of -40°C to 85°C.
LM567CM/NOPB
Tone Decoder IC, 0.5MHz, 4.75-9V, SOIC
ULN2003ADR
Seven-channel NPN Darlington transistor array for surface mounting in a 16-SOIC package. Features a 50V collector-emitter breakdown voltage and a maximum collector current of 500mA. Operates within a temperature range of -20°C to 70°C. This RoHS compliant component is designed for automotive applications and AEC-Q100 qualification.
CD40160
4000/14000/40000 SERIES, SYN POSITIVE EDGE TRIGGERED 4-BIT UP DECADE COUNTER, CDIP16, HERMETIC SEALED, CERAMIC, DIP-16
About TPA2005D1DGNR
The Texas Instruments TPA2005D1DGNR Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Mono Class-D audio amplifier delivering 1.4W output power into an 8 Ohm load. Features a wide operating voltage range of 2.5V to 5.5V and a low quiescent current of 2.8mA. Operates efficiently across a temperature range of -40°C to 85°C. Packaged in a compact HTSSOP EP with dimensions of 3mm x 3mm x 1.1mm, this lead-free component is supplied on tape and reel.. Key parameters include Height: 1.1mm, Lead Free: Lead Free, Length: 3mm, Load Impedance: 8R, and Max Operating Temperature: 85°C. TPA2005D1DGNR is manufactured by Texas Instruments as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Texas Instruments
- Category
- Semiconductors
Ask AI Assistant
Ask questions about TPA2005D1DGNR specifications
Click to ask a quick question:
Parameters
| Height | 1.1mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Load Impedance | 8R |
| Max Operating Temperature | 85°C |
| Max Output Power | 1.45W |
| Max Power Dissipation | 2.13W |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Number of Channels | 1 |
| Output Power | 1.4W |
| Package/Case | HTSSOP EP |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Power Dissipation | 2.13W |
| Power Supply Rejection Ratio (PSRR) | -75dB |
| Quest | 4659—————View offer |
| Quiescent Current | 2.8mA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Supply Current | 2.8mA |
| Supply Type | Single |
| Thickness | 1.02mm |
| Weight | 0.000861oz |
| Width | 3mm |
