LM7805
Fixed Positive Standard Regulator,
Similar Components
SPX3819M5-L-3-3/TR
Fixed positive linear voltage regulator (LDO) with a 3.3V output voltage. Features a maximum output current of 0.5A and a low dropout voltage of 0.7V. Operates with an input voltage range from 2.5V to 16V. Housed in a 5-terminal SOT-23 (PDSO5) package with dimensions of 1.6mm width and 2.9mm length. Offers a wide operating temperature range from -40°C to 125°C.
MP2303ADN-LF-Z
Switching Regulator, Current-mode, PDSO8, ROHS COMPLIANT, MS-012BA, SOIC-8
MP24943DN-LF-Z
Switching Regulator, Current-mode, 8A, PDSO8, ROHS COMPLIANT, MS-012BA, SOIC-8
L78L33ACZ
Positive fixed output voltage regulator, 3.3V nominal, with a maximum output current of 100mA. Features a 4% accuracy and a dropout voltage of 1.7V. Operates with a maximum input voltage of 30V and a minimum input voltage of 5.3V. Housed in a TO-92 package for through-hole mounting, with dimensions of 4.95mm height, 4.95mm length, and 3.94mm width. Offers a Power Supply Rejection Ratio (PSRR) of 49dB and a quiescent current of 6mA. RoHS compliant and lead-free.
LM337
Adjustable negative linear voltage regulator, offering output voltages from -1.25V to -37V with a maximum output current of 1.5A. Features include current limit, safe area protection, short circuit protection, and thermal protection. This surface-mount device utilizes a D2PAK (TO-263) package with gull-wing leads, a 3-pin configuration, and a tab for enhanced thermal performance. Operating within a -0°C to 125°C temperature range, it boasts a typical PSRR of 77 dB and a junction-to-case thermal resistance of 4°C/W.
L7805
The L7805 is a voltage regulator IC (Integrated Circuit) that is widely used in electronic circuits to provide a stable and regulated 5-volt DC output voltage. It is part of the L78xx series of voltage regulators, with each member of the series having a specific output voltage.
About LM7805
The Continental Device India LM7805 Power Supplies datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Fixed Positive Standard Regulator,. Key parameters include Input Voltage-Max: 25, Input Voltage-Min: 7, JEDEC Package Code: R-PSFM-T3, Military Spec: False, and Number of Functions: 1. LM7805 is manufactured by Continental Device India as part of their Power Supplies product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Continental Device India
- Category
- Power Supplies
Ask AI Assistant
Ask questions about LM7805 specifications
Click to ask a quick question:
Parameters
| Input Voltage-Max | 25 |
| Input Voltage-Min | 7 |
| JEDEC Package Code | R-PSFM-T3 |
| Military Spec | False |
| Number of Functions | 1 |
| Number of Terminals | 3 |
| Operating Temperature TJ-Max | 125 |
| Operating Temperature TJ-Min | 0 |
| Output Current1-Max | 1 |
| Output Voltage1-Max | 5.25 |
| Output Voltage1-Min | 4.75 |
| Output Voltage1-Nom | 5 |
| REACH | Compliant |
| Screening Level | TS 16949 |
| Terminal Position | SINGLE |
