74HC125
74HC125 CMOS IC, DIP14, 4-way Bus-Buffer (Tri-State) Texas Instruments
Similar Components
ADS1256
24-bit, 30 kSPS Delta-Sigma Analog-to-Digital Converter (ADC) with 8 analog inputs. Features a programmable gain amplifier (PGA), SPI interface, and bipolar polarity. Operates from 1.8V to 3.6V analog and 4.75V to 5.25V digital supply voltages. Housed in a 28-pin SSOP package with gold contact plating, suitable for surface-mount technology. RoHS compliant with a maximum power dissipation of 57mW and an operating temperature range of -40°C to 85°C.
LMC6482AIM
Dual operational amplifier featuring rail-to-rail input and output capabilities. Achieves ultra-low input bias current of 0.02pA and a low input offset voltage of 110µV. Offers a 1.5MHz bandwidth and 1.3V/µs slew rate. Operates from 3V to 15.5V supply voltages with a typical 1.3mA supply current. Housed in an 8-SOIC surface mount package.
LMD18200
Dual H-bridge motor driver IC for brushed DC motors, featuring a maximum supply voltage of 55V and a maximum output current of 3A per channel. This through-hole component, housed in a TO-220 package, offers a parallel interface for control and operates from a minimum supply voltage of 12V. It provides two independent output channels, with an operating supply current of 13mA. The device is RoHS compliant and lead-free.
LF356
JFET input operational amplifier featuring a 5MHz bandwidth and 12V/µs slew rate. This single-channel amplifier offers a 3mV input offset voltage and 30pA input bias current, with a 1.5µs settling time. Designed for through-hole mounting in an 8-PDIP package, it operates from a dual supply voltage range of ±10V to ±18V, with a maximum supply voltage of ±36V. Key performance metrics include 80dB common mode rejection ratio and 80dB power supply rejection ratio.
MAX232N
Dual transmitter/receiver bus transceiver for RS-232 communication. Features two transmitters and two receivers, supporting full-duplex operation. Operates with a 5V supply voltage (4.5V to 5.5V) and offers a data rate of 120Kbps. Includes ESD protection and is RoHS compliant. Packaged in a 16-pin PDIP with through-hole mounting.
TSC2007IPWR
12-Bit 4-Wire Touch Screen Controller, I2C/Serial, TSSOP
About 74HC125
The Texas Instruments 74HC125 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 74HC125 CMOS IC, DIP14, 4-way Bus-Buffer (Tri-State) Texas Instruments. Key parameters include Casing: DIP14, Manufacturer: Texas Instruments, RoHS: Not Compliant, Specification: 4-way Bus-Buffer (Tri-State), and Type: 74 HC 125. 74HC125 is manufactured by Texas Instruments as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Texas Instruments
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 74HC125 specifications
Click to ask a quick question:
Parameters
| Casing | DIP14 |
| Manufacturer | Texas Instruments |
| RoHS | Not Compliant |
| Specification | 4-way Bus-Buffer (Tri-State) |
| Type | 74 HC 125 |
