LM7912
LM7912
Similar Components
LM7905
Negative linear voltage regulator, fixed output voltage of -5V with 4% accuracy. Features a maximum output current of 1.5A and a dropout voltage of 1.1V. Operates within a temperature range of 0°C to 125°C, with a maximum input voltage of -25V. Packaged in a TO-220 through-hole mount.
TPS5430
Automotive 3A DC/DC buck converter with adjustable output voltage from 1.22V to 31V. Features a 5.5V to 36V input voltage range, 500kHz fixed frequency operation, and up to 95% efficiency. This surface mount component is housed in an 8-SO PowerPAD package, operating from -40°C to 125°C. It offers a single adjustable output and is RoHS compliant.
TPS63020
High efficiency single inductor buck-boost converter, featuring a 4A switch and 96% peak efficiency. This power management IC offers adjustable output voltage from 1.2V to 5.5V, supporting up to 3A output current. Designed for surface mount installation in a compact VSON package (4.15mm x 3.15mm x 0.95mm), it operates from 1.8V to 5.5V input voltage. With a quiescent current of 50µA and a wide operating temperature range of -40°C to 85°C, this RoHS compliant component is ideal for power-sensitive applications.
TL431AIDBZR
Adjustable precision shunt regulator, SOT-23 package, offering an output voltage range from 2.495V to 36V with a 1% tolerance. Features a maximum input voltage of 37V and a maximum output current of 100mA. Operates across a wide temperature range of -40°C to 125°C. This RoHS compliant component requires a minimum cathode current of 700µA.
BQ25601RTWR
The BQ25601RTWR is an industrial-grade power management IC with 24 terminals in a quad configuration. It operates over a temperature range of -40°C to 85°C and is supplied with a voltage between 3.9V and 13.5V. The device is packaged in a 4mm x 4mm HVQCCN package. It is a single-function device with two channels.
TPS7A4700RGWT
Positive adjustable LDO regulator with 1A maximum output current, offering an output voltage range of 1.4V to 20.5V. Features include ±1% accuracy, low dropout voltage (0.216V typical at 0.5A), and excellent line/load regulation. Operates from a 3V to 36V input, with typical PSRR of 78 dB and low output noise of 4.67 uVrms. Packaged in a 20-pin VQFN EP (5.15x5.15mm) for surface mounting, with integrated current limit and thermal shutdown protection.
About LM7912
The Texas Instruments LM7912 Power Supplies datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: LM7912. Key parameters include RoHS: Not Compliant. LM7912 is manufactured by Texas Instruments as part of their Power Supplies product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Texas Instruments
- Category
- Power Supplies
Ask AI Assistant
Ask questions about LM7912 specifications
Click to ask a quick question:
Parameters
| RoHS | Not Compliant |
