SN65HVD3082EDR
Half-duplex RS-485 transceiver, designed for robust communication. Features a 200Kbps data rate and operates over a wide temperature range of -40°C to 85°C. This surface-mount SOIC package component offers a 5V operating supply voltage, with a range of 4.5V to 5.5V. Includes one driver and one receiver, with 30mV receiver hysteresis for improved signal integrity. RoHS compliant and lead-free.
Similar Components
LM3915
10-segment dot/bar display driver IC, featuring a 3V to 25V input voltage range and a 3V to 25V supply voltage range. This integrated circuit offers 10 outputs with a maximum output current of 30mA and a typical output voltage of 1.28V. Housed in a 18-PDIP package, it supports through-hole mounting and operates within a temperature range of 0°C to 70°C. Maximum power dissipation is 1.365W with a maximum supply current of 9.2mA.
DRV8871DDA
45V 3.6A H-Bridge Motor Driver, 8-SO PowerPAD
CD4518
CMOS Dual BCD Up-Counter, featuring two independent 4-bit counters. Operates with a maximum frequency of 8MHz and a supply voltage range of 3V to 18V. Offers asynchronous reset functionality and synchronous operation. Packaged in a 16-TSSOP with gold contact plating, suitable for surface mounting. Operates across a wide temperature range from -55°C to 125°C.
TPA3116
Audio Amp Speaker 1-CH Mono/2-CH Stereo 50W Class-D 32-Pin HTSSOP EP Tube
LF356N/NOPB
JFET Op Amp, 5MHz BW, 12V/µs SR, 8-PDIP, Through Hole
NE555DR
Single channel timer IC, operating from 4.5V to 16V, with a frequency range up to 100kHz. Features include 200mA output current capability (both high and low level) and a maximum operating temperature of 70°C. This surface mount component is housed in an 8-pin SOIC package, measuring 4.9mm in length, 3.91mm in width, and 1.58mm in height. It is RoHS compliant and supplied on tape and reel.
About SN65HVD3082EDR
The Texas Instruments SN65HVD3082EDR Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Half-duplex RS-485 transceiver, designed for robust communication. Features a 200Kbps data rate and operates over a wide temperature range of -40°C to 85°C. This surface-mount SOIC package component offers a 5V operating supply voltage, with a range of 4.5V to 5.5V. Includes one driver and one receiver, with 30mV receiver hysteresis for improved signal integrity. RoHS compliant and lead-free.. Key parameters include Data Rate: 200Kbps, Height: 1.75mm, Interface: RS-485, Lead Free: Lead Free, and Length: 4.9mm. SN65HVD3082EDR is manufactured by Texas Instruments as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Texas Instruments
- Category
- Semiconductors
Ask AI Assistant
Ask questions about SN65HVD3082EDR specifications
Click to ask a quick question:
Parameters
| Data Rate | 200Kbps |
| Height | 1.75mm |
| Interface | RS-485 |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Logic Function | Transceiver |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Number of Transceivers | 1 |
| Number of Transmitters | 1 |
| Operating Supply Current | 900uA |
| Operating Supply Voltage | 5V |
| Package/Case | SOIC |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Receiver Hysteresis | 30mV |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Simplex/Duplex | Half Duplex |
| Supply Current | 900uA |
| Thickness | 1.58mm |
| TME | 1,4281$1.03$0.866$0.786$0.594pcsView offer |
| Weight | 0.002561oz |
| Width | 3.91mm |
