BZT52C3V6
The BZT52C3V6 is a surface mount zener diode with a maximum operating temperature range of -65°C to 150°C. It has a maximum power dissipation of 500mW and a zener voltage of 3.6V with a tolerance of 5%. The diode is RoHS compliant and packaged in tape and reel quantities of 3000.
Similar Components
BAW56
Diode SOT-23 75 V, BAW56
SK84C
Schottky Diodes & Rectifiers 8A,40V,SMD SCHOTTKY Rect
SS14
General purpose rectifier diode featuring a 1A output current and 40V DC rated voltage. This Schottky diode offers a 1A current rating and a maximum surge current of 30A. Operating within a temperature range of -65°C to 125°C, it exhibits a maximum reverse leakage current of 400uA. Packaged in SMA for tape and reel distribution, this component is lead-free, RoHS compliant, and REACH SVHC compliant.
SMAJ36CA
Bidirectional Transient Voltage Suppressor (TVS) diode, 400W peak pulse power, 36V reverse standoff voltage. Features 58.1V clamping voltage, 40A max surge current, and 6.9A peak pulse current. Operates from -55°C to 150°C, with 44.2V max breakdown voltage and 40V min breakdown voltage. Surface mountable in a DO-214AC package, offering ESD protection.
SS24
The SS24 is a general purpose rectifier diode with a maximum operating temperature of 125°C and a minimum operating temperature of -65°C. It has a maximum reverse leakage current of 400uA and a maximum surge current of 50A. The diode is available in a tape and reel packaging with 3000 units per package. It is compliant with RoHS and Reach SVHC regulations.
BZT52C4V7S
The BZT52C4V7S Zener diode from Taiwan Semiconductor features a Zener voltage of 4.7V with a tolerance of 5%. It can handle a maximum power dissipation of 200mW and has a maximum reverse leakage current of 1uA. The diode is designed for surface mount applications and has a maximum operating temperature range of -65°C to 150°C.
About BZT52C3V6
The Taiwan Semiconductor BZT52C3V6 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: The BZT52C3V6 is a surface mount zener diode with a maximum operating temperature range of -65°C to 150°C. It has a maximum power dissipation of 500mW and a zener voltage of 3.6V with a tolerance of 5%. The diode is RoHS compliant and packaged in tape and reel quantities of 3000.. Key parameters include Height: 1.15mm, Impedance: 90R, Length: 2.7mm, Max Operating Temperature: 150°C, and Max Power Dissipation: 500mW. BZT52C3V6 is manufactured by Taiwan Semiconductor as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Taiwan Semiconductor
- Category
- Semiconductors
Ask AI Assistant
Ask questions about BZT52C3V6 specifications
Click to ask a quick question:
Parameters
| Height | 1.15mm |
| Impedance | 90R |
| Length | 2.7mm |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 4.5uA |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Power Dissipation | 500mW |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Voltage Tolerance | 5% |
| Width | 1.7mm |
| Zener Voltage | 3.6V |
