BZT52C16
ZENER DIODE,SINGLE, TWO TERMINAL,16V V(Z),4.3%,SOD-123
Similar Components
BAW56
Diode SOT-23 75 V, BAW56
SS14
General purpose rectifier diode featuring a 1A output current and 40V DC rated voltage. This Schottky diode offers a 1A current rating and a maximum surge current of 30A. Operating within a temperature range of -65°C to 125°C, it exhibits a maximum reverse leakage current of 400uA. Packaged in SMA for tape and reel distribution, this component is lead-free, RoHS compliant, and REACH SVHC compliant.
SS16
The SS16 is a 60V 1A surface mount Schottky diode packaged in an SMA case. It has a maximum operating temperature range of -65°C to 150°C and is compliant with RoHS regulations. The diode's power dissipation is 400mW and its reverse recovery time is 25ns. It is available in quantities of 7500 per reel.
SMAJ36CA
Bidirectional Transient Voltage Suppressor (TVS) diode, 400W peak pulse power, 36V reverse standoff voltage. Features 58.1V clamping voltage, 40A max surge current, and 6.9A peak pulse current. Operates from -55°C to 150°C, with 44.2V max breakdown voltage and 40V min breakdown voltage. Surface mountable in a DO-214AC package, offering ESD protection.
B0520WS
Rectifier Diode,
BZT52C4V7S
The BZT52C4V7S Zener diode from Taiwan Semiconductor features a Zener voltage of 4.7V with a tolerance of 5%. It can handle a maximum power dissipation of 200mW and has a maximum reverse leakage current of 1uA. The diode is designed for surface mount applications and has a maximum operating temperature range of -65°C to 150°C.
About BZT52C16
The Taiwan Semiconductor BZT52C16 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: ZENER DIODE,SINGLE, TWO TERMINAL,16V V(Z),4.3%,SOD-123. Key parameters include Height: 1.15mm, Impedance: 40R, Length: 2.7mm, Max Operating Temperature: 150°C, and Max Power Dissipation: 500mW. BZT52C16 is manufactured by Taiwan Semiconductor as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Taiwan Semiconductor
- Category
- Semiconductors
Ask AI Assistant
Ask questions about BZT52C16 specifications
Click to ask a quick question:
Parameters
| Height | 1.15mm |
| Impedance | 40R |
| Length | 2.7mm |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 45nA |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Power Dissipation | 500mW |
| Reach SVHC Compliant | Yes |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Voltage Tolerance | 5% |
| Width | 1.7mm |
| Zener Voltage | 16V |
