74HC541
3-State Outputs Buffer/Driver 8x DIP20
Similar Components
LM358P
Dual operational amplifier IC featuring a 700kHz bandwidth and 100dB voltage gain. This general-purpose amplifier offers a 0.3V/µs slew rate and operates with a wide supply voltage range from 1.5V to 32V. Housed in a PDIP package for through-hole mounting, it includes two independent amplifier channels, each capable of 30mA output current. The device boasts a 65dB common mode rejection ratio and is RoHS compliant.
CD4069UBF
CMOS Hex Inverter 14-CDIP -55 to 125
TPA3116
Audio Amp Speaker 1-CH Mono/2-CH Stereo 50W Class-D 32-Pin HTSSOP EP Tube
CD4511
The CD4511BF3A is a CMOS decoder/latch IC with 4 inputs and 7 outputs. It operates over a supply voltage range of 3V to 18V and can withstand temperatures between -55°C and 125°C. The device is packaged in a DIP-16 configuration and features a non-inverting polarity. The IC has a propagation delay of 1320ns and a turn-on delay time of 1320ns, with a quiescent current of 100uA. The CD4511BF3A is not radiation hardened and is not RoHS compliant.
CD4027BE
JK Flip-Flop IC, 2-Element, 24MHz, 18V, PDIP, CMOS
INA2126UAE4
Dual instrumentation amplifier with a 9kHz bandwidth and 200kHz -3dB bandwidth. Features a 74dB Common Mode Rejection Ratio, 500µV input offset voltage, and 50nA input bias current. Operates with dual supply voltages from ±1.35V to ±18V or a single supply from 2.7V to 36V. Offers 80dB voltage gain, 0.4V/µs slew rate, and 35nV/√Hz input voltage noise density. Packaged in a D surface-mount case, this RoHS compliant component is suitable for a wide operating temperature range of -40°C to 85°C.
About 74HC541
The Texas Instruments 74HC541 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 3-State Outputs Buffer/Driver 8x DIP20. Key parameters include Logic Function: Buffer and RoHS: Not Compliant. 74HC541 is manufactured by Texas Instruments as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Texas Instruments
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 74HC541 specifications
Click to ask a quick question:
Parameters
| Logic Function | Buffer |
| RoHS | Not Compliant |
