A-DF15A/KG-T1
15-Contact Right Angle Female Connector, 3A, 250V, Through Hole Mount
Similar Components
687650050002
FFC Jumper Cable, 0.5mm Pitch, 50mm L, 500mA, 60V
PCF0402R-100KBI
100K Ohm .063W.1% 25PPM
686610200001
FFC Cable 10 Pos 1mm Pitch 200mm L 1A 60V
686721152001
Flat flexible cable FFC-FFC Number of poles 21, 0.15 m, 686721152001, Würth Elektronik
4020
Grey Rubber Cable Mount, 36mm L, PG36
7499012121
WURTH ELEKTRONIK 7499012121 Modular Connector, RJ45, Jack, 8 Contacts, 8 Ways, 1 Ports
About A-DF15A/KG-T1
The Assmann A-DF15A/KG-T1 Uncategorized datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 15-Contact Right Angle Female Connector, 3A, 250V, Through Hole Mount. Key parameters include Contact Material: Brass, Bronze, Gold, Contact Plating: Nickel, Gold, Current Rating: 3A, Depth: 12.55mm, and Gender: Female. A-DF15A/KG-T1 is manufactured by Assmann as part of their Uncategorized product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Assmann
- Category
- Uncategorized
Ask AI Assistant
Ask questions about A-DF15A/KG-T1 specifications
Click to ask a quick question:
Parameters
| Contact Material | Brass, Bronze, Gold |
| Contact Plating | Nickel, Gold |
| Current Rating | 3A |
| Depth | 12.55mm |
| Gender | Female |
| Length | 39.14mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 15 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Pitch | 2.77mm |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Series | A-DF |
| Voltage Rating | 250V |
