74HC00
4x 2-Input NAND Gate DIP14
Similar Components
HIN232ECBZ
The HIN232ECBZ is a commercial-grade, 16-pin SOIC-packaged, dual-line transceiver with a Schmitt trigger input characteristic. It operates over a temperature range of 0 to 70 degrees Celsius and is supplied with a nominal voltage of 5V, with a minimum of 4.5V and a maximum of 5.5V. The device is a type of interface IC, specifically designed for bus transceiver applications.
BK/HTB-94I-R
This 250V panel mount fuse has a current rating of 20A and is rated for operation between -55°C and 85°C. It features a quick connect termination and is lead free. The fuse is packaged in bulk quantities of 100.
CD4040
CMOS ripple-carry binary counter/divider provides 12 counter stages built from master-slave flip-flops. The counter advances on the negative transition of each input pulse, and a high level on RESET clears all stages to zero. Schmitt-trigger action on the input-pulse line permits unlimited rise and fall times, and all inputs and outputs are buffered. The device operates from 3 V to 18 V supplies across a -55°C to 125°C operating temperature range.
00184
Test Accessories - Other MICROPHONE HOLDER 88
SMDJ58A
Unidirectional Transient Voltage Suppressor (TVS) diode, 3kW peak pulse power, 58V reverse standoff voltage, and 93.6V clamping voltage. Features a 32.1A peak pulse current rating, 2µA leakage current, and operates across a -65°C to 150°C temperature range. This silicon diode is housed in a DO-214AB (SMC) package for surface mounting, offering 1 element and 1 unidirectional channel. RoHS compliant and lead-free.
TL071CP
JFET input operational amplifier featuring a 3MHz bandwidth and 13V/µs slew rate. This single-channel amplifier offers a 200pA input bias current and 10mV input offset voltage. Operating with dual supply voltages from 3.5V to 18V, it provides a 70dB common mode rejection ratio and 106.02dB voltage gain. Packaged in a 1-amplifier configuration, it operates within a -40°C to 85°C temperature range.
About 74HC00
The Renesas 74HC00 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 4x 2-Input NAND Gate DIP14. Key parameters include Logic Function: NAND GATE and RoHS: Not Compliant. 74HC00 is manufactured by Renesas as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Renesas
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 74HC00 specifications
Click to ask a quick question:
Parameters
| Logic Function | NAND GATE |
| RoHS | Not Compliant |
