4245
15A PCB Mount Fuseholder, 500V, Illuminated, Snap-In, PC Pin
Similar Components
3587TR
Illuminated Fuse Holder, 20A, 500V, SMT, Vertical, Brass
3526
500V 15A Brass Fuse, Illuminated, Horizontal Mount, -50°C to 145°C
3573
Clip; Automotive Fuse; 0.480 in. x 0.292 in.; Nickel Plated Brass; Through Hole Mount
3527
6.3A 250VAC Fuse Holder, PCB Mount, Tin Plated Brass
3524
Fuseholder; 3AG Fuses; 3000 VDC; Panel Mount; UL Listed
3533
15A Fuse Clip, Brass, Nickel, SMD/SMT, PCB Mount
About 4245
The Keystone Electronics 4245 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 15A PCB Mount Fuseholder, 500V, Illuminated, Snap-In, PC Pin. Key parameters include Approvals: UL, Color: Black, Contact Material: Brass, Contact Plating: Tin, and Current Rating: 15A. 4245 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 4245 specifications
Click to ask a quick question:
Parameters
| Approvals | UL |
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Tin |
| Current Rating | 15A |
| DC Rated Voltage | 3kV |
| Flammability Rating | UL94 V-0 |
| Fuse Current | 15A |
| Fuse Size | 0.25 Dia x 1.26 L (6.35mm x 32mm) |
| Height | 10.9mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 34.2m |
| Material | Brass, Tin, PBT |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Through Hole, Horizontal, PCB |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Orientation | Horizontal |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Not Compliant |
| Termination | PC Pin |
| Voltage | 500V |
| Voltage Rating | 500V |
| Voltage Rating (AC) | 500V |
| Width | 7.24mm |
