3523
15A 250V Illuminated Fuse Holder, Polymer, Brass, UL, Chassis Mount
Similar Components
3559
500V 20A Free Hanging Fuse, Illuminated, Lead Free, UL94 V-0
3541
15A 500V Brass Chassis Mount Fuse
3527C
PVC Fuse Cover, 5mm, UL94 V-0
3524
Fuseholder; 3AG Fuses; 3000 VDC; Panel Mount; UL Listed
3553
250V 5A Radial Fuse with Illuminated Indicator
3526
500V 15A Brass Fuse, Illuminated, Horizontal Mount, -50°C to 145°C
About 3523
The Keystone Electronics 3523 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 15A 250V Illuminated Fuse Holder, Polymer, Brass, UL, Chassis Mount. Key parameters include Approvals: UL, Body Material: Polymer, Color: Black, Contact Material: Brass, and Contact Plating: Nickel. 3523 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 3523 specifications
Click to ask a quick question:
Parameters
| Approvals | UL |
| Body Material | Polymer |
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Nickel |
| Current Rating | 15A |
| DC Rated Voltage | 3kV |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Height | 17.9mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 41.3mm |
| Material | Brass, Polymer, Liquid Crystal Polymer |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Chassis Mount, Rivet |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package/Case | Molded |
| Package Quantity | 1 |
| Packaging | Bulk |
| RoHS | Not Compliant |
| Termination | Solder |
| Voltage | 250V |
| Voltage Rating | 500V |
| Width | 28.6mm |
