3539
4-Pole 15A 500V Fuse Holder, Illuminated, Black
Similar Components
3561
CLIP FUSE 2AG/5MM SMD W/HOLE 10A
3533
15A Fuse Clip, Brass, Nickel, SMD/SMT, PCB Mount
3540
Fuse Holder HIGH UL RTG FUSE HOLDER
3573
Clip; Automotive Fuse; 0.480 in. x 0.292 in.; Nickel Plated Brass; Through Hole Mount
4525
10A 250V Illuminated Fuse Holder, PCB Mount, Horizontal
3527
6.3A 250VAC Fuse Holder, PCB Mount, Tin Plated Brass
About 3539
The Keystone Electronics 3539 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 4-Pole 15A 500V Fuse Holder, Illuminated, Black. Key parameters include Color: Black, Contact Material: Brass, Contact Plating: Nickel, Current Rating: 15A, and DC Rated Voltage: 3kV. 3539 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 3539 specifications
Click to ask a quick question:
Parameters
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Nickel |
| Current Rating | 15A |
| DC Rated Voltage | 3kV |
| Flammability Rating | UL94 HB |
| Fuse Current | 15A |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 41.3mm |
| Material | Brass, Phenolic |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Chassis Mount, Rivet |
| Number of Circuits | 4 |
| Number of Poles | 4 |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Termination | Solder |
| Voltage | 500V |
| Voltage Rating | 500V |
| Voltage Rating (AC) | 500V |
| Width | 60.3mm |
