3568
Fuse Holder, 20A 500VAC, Illuminated, PCB Mount, Nylon
Similar Components
3562
15A 3AG/5mm PCB Fuse Clip - Brass/Tin, UL Approved
3522-3
30A 500V ATO/ATC Fuse, Brass, Tin, Vertical, Through Hole Mount
4525
10A 250V Illuminated Fuse Holder, PCB Mount, Horizontal
3532
Chassis Mount, PCB, Rivet Fuse, 15A, 1/4\
3527C
PVC Fuse Cover, 5mm, UL94 V-0
3558
Holder; Fuse; Auto Blade; Modular; 500VAC; 30A; PC Pin Terminal; Nylon 6/6 Holder; Black
About 3568
The Keystone Electronics 3568 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Fuse Holder, 20A 500VAC, Illuminated, PCB Mount, Nylon. Key parameters include Approvals: UL, Body Material: Nylon, Color: Black, Contact Material: Brass, Tin, and Contact Plating: Tin. 3568 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 3568 specifications
Click to ask a quick question:
Parameters
| Approvals | UL |
| Body Material | Nylon |
| Color | Black |
| Contact Material | Brass, Tin |
| Contact Plating | Tin |
| Current Rating | 20A |
| Flammability Rating | UL94 V-0 |
| Fuse Current | 20A |
| Fuse Size | Mini ATO, ATC |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Material | Brass, Tin, Nylon |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Vertical, PCB |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Orientation | Vertical |
| Package Quantity | 1 |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Series | MINI® 297 |
| Termination | PC Pin |
| Voltage | 500V |
| Voltage Rating (AC) | 500V |
