4247
15A Fuse Clip, Brass, Nickel Plated, Quick Connect, Chassis Mount
Similar Components
3537
Fuse Holder
3521
10A 2AG/5mm Fuse Clip, THM, Horizontal PCB Mount, Brass/Tin
3559
500V 20A Free Hanging Fuse, Illuminated, Lead Free, UL94 V-0
4527C
5A 250V Quick Connect Fuse, 5 x 20mm, Lead Free, PCB Mount
3527C
PVC Fuse Cover, 5mm, UL94 V-0
3513
FUSE CLIP SNAP-IN PC LEGS
About 4247
The Keystone Electronics 4247 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 15A Fuse Clip, Brass, Nickel Plated, Quick Connect, Chassis Mount. Key parameters include Body Material: Brass, Contact Material: Brass, Contact Plating: Nickel, Current Rating: 15A, and Fuse Size: 0.25 Dia (6.35mm). 4247 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 4247 specifications
Click to ask a quick question:
Parameters
| Body Material | Brass |
| Contact Material | Brass |
| Contact Plating | Nickel |
| Current Rating | 15A |
| Fuse Size | 0.25 Dia (6.35mm) |
| Height | 11.5mm |
| Lead Free | Lead Free |
| Length | 7.9mm |
| Material | Brass |
| Mount | Chassis Mount |
| Number of Circuits | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| RoHS | Compliant |
| Termination | Quick Connect |
