3564
500V 30A Mini ATO/ATC Fuse Holder, Illuminated, PCB Mount
Similar Components
3549-2
Illuminated Fuse Holder, 15A, 500V, Mini ATO/ATC, PCB Mount
3544
30A 500V Fuse Clip, Through Hole, Brass, Tin Plated
3524
Fuseholder; 3AG Fuses; 3000 VDC; Panel Mount; UL Listed
3622
Clip Cylindrical Fuse; 0.197 in. Dia. Fuse; Tin Plated Brass; 0.067 in. Mount
3518P
15A Brass Fuse, 5mm Dia, Lead Free, Through Hole Mount
3560
Illuminated Fuse Holder, 20A, 500V, PCB Mount, ATO/ATC
About 3564
The Keystone Electronics 3564 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 500V 30A Mini ATO/ATC Fuse Holder, Illuminated, PCB Mount. Key parameters include Color: Grey, Contact Material: Brass, Contact Plating: Tin, Current Rating: 30A, and DC Rated Voltage: 500V. 3564 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 3564 specifications
Click to ask a quick question:
Parameters
| Color | Grey |
| Contact Material | Brass |
| Contact Plating | Tin |
| Current Rating | 30A |
| DC Rated Voltage | 500V |
| Fuse Current | 30A |
| Fuse Size | Mini ATO, ATC |
| Height | 5mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 6mm |
| Material | Brass, Tin |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Vertical, PCB, Through Hole |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Orientation | Vertical |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Termination | PC Pin |
| Voltage | 500V |
| Voltage Rating | 500V |
| Voltage Rating (AC) | 500V |
