About 24C16
The Microchip 24C16 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 24C16/P. Key parameters include JEDEC Package Code: R-PDIP-T8, Max Operating Temperature: 70, Memory IC Type: EEPROM, Military Spec: False, and Min Operating Temperature: -55. 24C16 is manufactured by Microchip as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Microchip
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 24C16 specifications
Click to ask a quick question:
Parameters
| JEDEC Package Code | R-PDIP-T8 |
| Max Operating Temperature | 70 |
| Memory IC Type | EEPROM |
| Military Spec | False |
| Min Operating Temperature | -55 |
| Number of Terminals | 8 |
| Number of Words | 2048 |
| Number of Words Code | 2000 |
| Parallel/Serial | SERIAL |
| REACH | unknown |
| RoHS | No |
| Standby Current-Max | 0.0001 |
| Supply Current-Max | 0.003 |
| Supply Voltage-Nom (Vsup) | 5 |
| Temperature Grade | OTHER |
| Terminal Position | DUAL |
