OP07
OP07
Similar Components
TDA7498
The TDA7498 is a 2-channel stereo audio amplifier in a PowerSSO EP package, suitable for surface mount. It operates over a temperature range of -40 to 85 degrees Celsius. The amplifier is a Class-D type, with differential input and output signals. It is designed for speaker applications.
STP55NF06
N-channel power MOSFET featuring 60V drain-source breakdown voltage and 50A continuous drain current. This component offers a low 18mΩ drain-source on-resistance and 110W maximum power dissipation. Designed for through-hole mounting in a TO-220 package, it operates within a -55°C to 175°C temperature range. Key switching characteristics include a 20ns turn-on delay and 36ns turn-off delay.
L6203
Dual-channel, full-bridge motor driver IC for brushed DC motors. Features a maximum supply voltage of 48V and a maximum output current of 5A per channel, with a 4A continuous output current. Operates with a 12V to 36V supply voltage and includes over-temperature fault protection. Utilizes BCDMOS technology with a 550mR maximum on-state resistance. Packaged in a 11-pin MULTIWATT V for through-hole mounting.
TDA2030A
AUDIO AMPLIFIER
BCP56-16
NPN Bipolar Junction Transistor (BJT) for low-power applications. Features an 80V Collector-Emitter Voltage (VCEO) and 1A Max Collector Current. Offers a 500mV Collector-Emitter Saturation Voltage and 40 minimum hFE. Packaged in a SOT-223 surface-mount case, this RoHS compliant component operates from -65°C to 150°C with 1.6W power dissipation.
USBLC6-2SC6
High-performance ESD suppressor diode array for robust protection. Features a low capacitance of 3.5pF and a clamping voltage of 17V, supporting data rates up to 480Mbps. Designed for surface mount applications in a compact SOT-23 package, offering unidirectional and bidirectional protection. Operates within a voltage range of 5.25V reverse standoff voltage and 6V breakdown voltage, with a low leakage current of 150nA. Suitable for a wide operating temperature range from -40°C to 125°C.
About OP07
The Stmicroelectronics OP07 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: OP07. Key parameters include RoHS: Not Compliant. OP07 is manufactured by Stmicroelectronics as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Stmicroelectronics
- Category
- Semiconductors
Ask AI Assistant
Ask questions about OP07 specifications
Click to ask a quick question:
Parameters
| RoHS | Not Compliant |
