MMBT5401
PNP Bipolar Junction Transistor (BJT) in SOT-23 package. Features 150V collector-emitter voltage (VCEO) and 600mA maximum collector current. Operates with a transition frequency of 300MHz and a maximum power dissipation of 350mW. This surface mount device is RoHS compliant and operates across a temperature range of -55°C to 150°C.
Similar Components
P6SMB6.8CA
Bi-directional Transient Voltage Suppressor (TVS) diode for circuit protection. Features a 58.1V reverse stand-off voltage and 600W peak pulse power dissipation. This single element device offers a maximum clamping voltage of 92V and a maximum peak pulse current of 6.5A. Packaged in a 2-pin SMB (DO-214AA) surface-mount plastic package with J-lead configuration, it operates across a wide temperature range of -65°C to 150°C.
MMSZ5257B
Diode Zener Single 33V 5% 500mW 2-Pin SOD-123 T/R
BAT54A
DIODE ARRAY SCHOTTKY 30V SOT23-3
SMF05CT1G
5-line ESD protection array for safeguarding sensitive electronics. Features 5 unidirectional Zener diodes with a 5V DC rated voltage and 12.5V clamping voltage. Offers a 6.2V reverse breakdown voltage and a low 5uA leakage current. Designed for surface-mount applications in a compact SC-88/SC70-6/SOT-363 6-lead package. Handles up to 100W peak pulse power and 8A peak pulse current.
MMBT3906
PNP Bipolar Junction Transistor in SOT-23 package. Features a 40V collector-emitter breakdown voltage and a maximum collector current of 200mA. Offers a minimum DC current gain (hFE) of 100 and a transition frequency of 250MHz. Operates within a temperature range of -55°C to 150°C with a maximum power dissipation of 350mW. Surface mountable and RoHS compliant.
BZX84C30
Surface mount Zener diode with a 30V DC rated voltage and 30V Zener voltage. Features 350mW power dissipation, 7% tolerance, and 80 Ohm impedance. Encased in a SOT-23 package with tin matte contact plating, this RoHS compliant component operates from -55°C to 150°C.
About MMBT5401
The Onsemi MMBT5401 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: PNP Bipolar Junction Transistor (BJT) in SOT-23 package. Features 150V collector-emitter voltage (VCEO) and 600mA maximum collector current. Operates with a transition frequency of 300MHz and a maximum power dissipation of 350mW. This surface mount device is RoHS compliant and operates across a temperature range of -55°C to 150°C.. Key parameters include Collector Base Voltage (VCBO): 160V, Collector Emitter Breakdown Voltage: 150V, Collector Emitter Saturation Voltage: -500mV, Collector-emitter Voltage-Max: 500mV, and Collector Emitter Voltage (VCEO): 150V. MMBT5401 is manufactured by Onsemi as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Onsemi
- Category
- Semiconductors
Ask AI Assistant
Ask questions about MMBT5401 specifications
Click to ask a quick question:
Parameters
| Collector Base Voltage (VCBO) | 160V |
| Collector Emitter Breakdown Voltage | 150V |
| Collector Emitter Saturation Voltage | -500mV |
| Collector-emitter Voltage-Max | 500mV |
| Collector Emitter Voltage (VCEO) | 150V |
| Current Rating | -600mA |
| DC Rated Voltage | -150V |
| Emitter Base Voltage (VEBO) | 5V |
| Frequency | 300MHz |
| Height | 0.96mm |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Max Breakdown Voltage | 150V |
| Max Collector Current | 600mA |
| Max Frequency | 300MHz |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 350mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Package/Case | SOT-23 |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Polarity | PNP |
| Power Dissipation | 350mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Transition Frequency | 300MHz |
| Voltage | 150V |
| Width | 1.3mm |
