MDA-1/4-R
250V 250mA Ceramic Fuse Holder, Clip Termination, UL/CSA/CE
Similar Components
HEB-KW-RYC
Fuse Holder
160EET
Fuse 160A 690V Bolt 46 X 37 X 19mm Carton UL
CM100CF
600V 100A DIN Rail Fuse Holder
BK/S501-50-R
50mA 250V AC Fuse Holder, Nickel Contact Plating, 5mm x 20mm, Lead Free
HM60400-1CR
600V 400A Surface Mount Fuse
LPJ-300SPI
300A Bolt Mount Fuse, 600V AC, 300V DC, UL, CSA, CE Approvals
About MDA-1/4-R
The Eaton MDA-1/4-R Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 250V 250mA Ceramic Fuse Holder, Clip Termination, UL/CSA/CE. Key parameters include Approvals: UL, CSA, CE, Body Material: Ceramic, Current Rating: 250mA, DC Cold Resistance: 9.325R, and DC Rated Voltage: 250V. MDA-1/4-R is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about MDA-1/4-R specifications
Click to ask a quick question:
Parameters
| Approvals | UL, CSA, CE |
| Body Material | Ceramic |
| Current Rating | 250mA |
| DC Cold Resistance | 9.325R |
| DC Rated Voltage | 250V |
| Diameter | 6.35mm |
| Fuse Size | 6.35 X 31.75mm |
| Length | 31.75mm |
| Max Voltage Rating (AC) | 250V |
| Mount | Holder, Clip |
| Packaging | Bulk |
| Radiation Hardening | No |
| Resistance | 8.7R |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Series | MDA |
| Termination | Clip |
| Voltage Rating (AC) | 250V |
| Weight | 0.016oz |
