JTEP-4-1REC4-52-3-B2-800
Circuit Breaker Magnetic 4Pole 800A 160VDC
Similar Components
UPL1111-1-42-502
Circuit Breaker Magnetic 4Pole
209-1-1-61F-4-8-22
Circuit Breaker Magnetic 1Pole 22A 240VAC
AP12-1-41-702
Hydraulic Magnetic Switch, 2-Pole, 240VAC, 7A, 0.055s to 0.95s Trip Time
AP1-1RC-42-102
Hydraulic Magnetic Circuit Breaker, 240VAC, 1A, Handle Actuator, -40 to 100°C
AP112-1RC-71-103
Hydraulic Magnetic 3-Pole 240VAC 10A Panel Mount Switch
UPL11-1REC4-61-303
Hydraulic Magnetic Relay, 2-Pole, 30A, 0.18s to 1.8s Trip Time, -40 to 85°C
About JTEP-4-1REC4-52-3-B2-800
The Sensata JTEP-4-1REC4-52-3-B2-800 Hardware datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Circuit Breaker Magnetic 4Pole 800A 160VDC. Key parameters include Actuator Type: Toggle, AEC Qualified: No, Automotive: No, Cage Code: 82647, and Current Rating: 800. JTEP-4-1REC4-52-3-B2-800 is manufactured by Sensata as part of their Hardware product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Sensata
- Category
- Hardware
Ask AI Assistant
Ask questions about JTEP-4-1REC4-52-3-B2-800 specifications
Click to ask a quick question:
Parameters
| Actuator Type | Toggle |
| AEC Qualified | No |
| Automotive | No |
| Cage Code | 82647 |
| Current Rating | 800 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| HTS Code | 8536200020 |
| Max Operating Temperature | 85 |
| Min Operating Temperature | -40 |
| Mounting | Panel Mount |
| Number of Poles | 4 |
| Number of Terminals | 8 |
| PPAP | No |
| Radiation Hardening | No |
| RoHS Versions | 2011/65/EU, 2015/863 |
| Schedule B | 8536200020 |
| Trip Time | 2s to 15s |
| Type | Hydraulic Magnetic |
| Voltage Rating | 160VDC |
