ESP32-WROOM-32
The ESP32-WROOM-32E-N4 is a powerful, generic Wi-Fi + BT + BLE MCU module designed for a wide variety of applications, ranging from low-power sensor networks to demanding tasks such as voice encoding, music streaming, and MP3 decoding. It is based on the ESP32-D0WD-V3 SoC, featuring two individually controllable CPU cores with an adjustable clock frequency from 80 MHz to 240 MHz. The module integrates 4MB of external SPI flash and supports an operating temperature range of -40°C to 85°C. It includes an on-board PCB antenna and a rich set of peripherals including touch sensors, Hall sensors, and high-speed SPI/UART/I2C interfaces.
Similar Components
STM32F030F4P6
32-bit ARM Cortex-M0 microcontroller featuring 16KB FLASH memory and 4KB RAM. Operates at a maximum frequency of 48MHz with a 32-bit data bus. Offers I2C, SPI, and UART/USART interfaces, 11 ADC channels, and 15 I/Os. Supports a supply voltage range of 2.4V to 3.6V and operates from -40°C to 85°C. Includes peripherals like POR, PWM, WDT, and DMA. Packaged in TSSOP.
PIC18F27Q43-I/SO
8-bit RISC microcontroller featuring 128KB Flash, 8KB RAM, and 1KB EEPROM. Offers a 64MHz clock frequency, 25 I/O lines, and includes a 12-bit ADC2, 8-bit DAC, comparator, and 16-bit PWM. Designed for industrial temperature ranges (-40°C to 85°C) with a 1.8V to 5.5V supply voltage. Packaged in a 28-terminal R-PDSO-G28 (SOIC) package.
ATXMEGA128A4U-AU
AVR MCU 128KB FLASH 32MHz 16b 34 I/O 44TQFP
ATMEGA8535L-8PU
8-Bit AVR MCU 8KB FLASH 8MHz 40-DIP 32 I/O I2C SPI UART
ATmega8A
8-bit AVR microcontroller featuring 8KB FLASH memory and 1KB RAM. Operates at up to 16MHz with an internal oscillator. Offers 23 I/O pins, 8 ADC channels, and 3 PWM channels. Supports I2C, SPI, and UART/USART interfaces. Packaged in a 32-pin VQFN surface mount case, operating from 2.7V to 5.5V and -40°C to 85°C.
ESP8266EX
Highly integrated Wi-Fi 4 SoC provides 802.11 b/g/n connectivity in the 2.4 GHz band with station, SoftAP, and combined station plus SoftAP modes. The device integrates a Tensilica L106 32-bit processor running up to 160 MHz, on-chip SRAM, RF front end functions, power management, and interfaces including UART, SDIO, SPI, I2C, I2S, GPIO, PWM, IR, and ADC. It operates from 2.5 V to 3.6 V across a -40 °C to 125 °C temperature range and is supplied in a 32-pin 5 mm x 5 mm QFN package. The lifecycle status is not recommended for new designs.
About ESP32-WROOM-32
The SCHTOETA ENGINEERING LIMITED ESP32-WROOM-32 Computing Embedded Systems datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: The ESP32-WROOM-32E-N4 is a powerful, generic Wi-Fi + BT + BLE MCU module designed for a wide variety of applications, ranging from low-power sensor networks to demanding tasks such as voice encoding, music streaming, and MP3 decoding. It is based on the ESP32-D0WD-V3 SoC, featuring two individually controllable CPU cores with an adjustable clock frequency from 80 MHz to 240 MHz. The module integrates 4MB of external SPI flash and supports an operating temperature range of -40°C to 85°C. It includes an on-board PCB antenna and a rich set of peripherals including touch sensors, Hall sensors, and high-speed SPI/UART/I2C interfaces.. Key parameters include Antenna Type: On-board PCB Antenna, Bluetooth Version: V4.2 BR/EDR and BLE, Core Frequency: 240MHz, Data Rate (Max): 150Mbps, and Flash Memory Size: 4MB. ESP32-WROOM-32 is manufactured by SCHTOETA ENGINEERING LIMITED as part of their Computing Embedded Systems product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- SCHTOETA ENGINEERING LIMITED
- Category
- Computing Embedded Systems
Ask AI Assistant
Ask questions about ESP32-WROOM-32 specifications
Click to ask a quick question:
Parameters
| Antenna Type | On-board PCB Antenna |
| Bluetooth Version | V4.2 BR/EDR and BLE |
| Core Frequency | 240MHz |
| Data Rate (Max) | 150Mbps |
| Flash Memory Size | 4MB |
| Interface | UART, SPI, SDIO, I2C, LED PWM, Motor PWM, I2S, IR, Pulse Counter, GPIO, Capacitive Touch Sensor, ADC, DAC |
| Microcontroller | ESP32-D0WD-V3 (Xtensa Dual-Core 32-bit LX6) |
| Operating Temperature Range | -40 to 85°C |
| Operating Voltage | 3.0 to 3.6V |
| Output Power | 20dBm |
| Regulatory | FCC/CE/IC/TELEC/KCC/SRRC/NCC |
| RF Frequency Range | 2412 to 2484MHz |
| RoHS | Compliant |
| SRAM | 520KB |
| Wi-Fi Protocol | 802.11 b/g/n |
