BZT52C5V6
The BZT52C5V6 is a surface mount zener diode with a zener voltage of 5.6V and a voltage tolerance of 5%. It has a maximum power dissipation of 500mW and a maximum reverse leakage current of 900nA. The diode is rated for operation between -65°C and 150°C. It is available in a tape and reel packaging with 3000 units per package.
Similar Components
SK86C
The SK86C is a rectifier diode from Taiwan Semiconductor with a maximum repetitive reverse voltage of 60V and a maximum forward current of 8A. It features a maximum operating temperature of 150°C and a minimum operating temperature of -55°C. The diode is packaged in a SMC package and is available in quantities of 3000. It is compliant with RoHS regulations and is packaged on tape and reel for easy handling.
SK84C
Schottky Diodes & Rectifiers 8A,40V,SMD SCHOTTKY Rect
BZT52C24S
Zener Diodes 24 Volt 200mW 5%
SSL34F
Schottky Diodes & Rectifiers Low VF 3Amp 40v SMD Schottky Rect
BAW56
Diode SOT-23 75 V, BAW56
SMAJ36CA
Bidirectional Transient Voltage Suppressor (TVS) diode, 400W peak pulse power, 36V reverse standoff voltage. Features 58.1V clamping voltage, 40A max surge current, and 6.9A peak pulse current. Operates from -55°C to 150°C, with 44.2V max breakdown voltage and 40V min breakdown voltage. Surface mountable in a DO-214AC package, offering ESD protection.
About BZT52C5V6
The Taiwan Semiconductor BZT52C5V6 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: The BZT52C5V6 is a surface mount zener diode with a zener voltage of 5.6V and a voltage tolerance of 5%. It has a maximum power dissipation of 500mW and a maximum reverse leakage current of 900nA. The diode is rated for operation between -65°C and 150°C. It is available in a tape and reel packaging with 3000 units per package.. Key parameters include Height: 1.15mm, Impedance: 40R, Length: 2.7mm, Max Operating Temperature: 150°C, and Max Power Dissipation: 500mW. BZT52C5V6 is manufactured by Taiwan Semiconductor as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Taiwan Semiconductor
- Category
- Semiconductors
Ask AI Assistant
Ask questions about BZT52C5V6 specifications
Click to ask a quick question:
Parameters
| Height | 1.15mm |
| Impedance | 40R |
| Length | 2.7mm |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 900nA |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | Yes |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Voltage Tolerance | 5% |
| Width | 1.7mm |
| Zener Voltage | 5.6V |
