78L12
Fixed Positive Standard Regulator, 12VBIPolar, PSSO3, SOT-89, 3 PIN
Similar Components
MP2307
Switching Regulator, Current-mode, 3A, 380kHz Switching Freq-Max, PDSO8, LEAD FREE, SOIC-8
LM1117DT-ADJ/NOPB
800mA Adj LDO, 15V In, 1.2V Dropout, 1% Acc, TO-252
LT1073CS8#PBF
Adjustable Positive 50V 400mA DC/DC Controller, SOIC Package, 0°C to 70°C
LM7812ACT
1A positive fixed voltage regulator, 12V output, 2% accuracy. Features 2V dropout voltage, 35V max input, and 1A max output current. Operates from 0°C to 125°C in a TO-220-3 through-hole package. RoHS compliant with 71dB PSRR.
LM2577
Adjustable DC-DC converter with a 3A maximum output current. Features a wide input voltage range from 3.5V to 40V and an adjustable output voltage from 1.23V up to 60V. This boost converter offers up to 80% efficiency and operates within a temperature range of -40°C to 125°C. Packaged in a 5-pin TO-220 through-hole mount, it supports a single positive output.
TPS54531DDAR
5A, 570kHz step-down converter with adjustable output voltage from 800mV to 26.04V. Features a wide input voltage range of 3.5V to 28V and a maximum output current of 5A. Operates within a temperature range of -40°C to 85°C. Includes Eco-mode for improved efficiency and is packaged in a lead-free, surface-mount 8-SO PowerPAD.
About 78L12
The Unisonic Technologies 78L12 Power Supplies datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Fixed Positive Standard Regulator, 12VBIPolar, PSSO3, SOT-89, 3 PIN. Key parameters include Adjustability: FIXED, Dropout Voltage1-Nom: 1.7, Eccn Code: EAR99, HTS Code: 8542.39.00.01, and Input Voltage Absolute-Max: 35. 78L12 is manufactured by Unisonic Technologies as part of their Power Supplies product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Unisonic Technologies
- Category
- Power Supplies
Ask AI Assistant
Ask questions about 78L12 specifications
Click to ask a quick question:
Parameters
| Adjustability | FIXED |
| Dropout Voltage1-Nom | 1.7 |
| Eccn Code | EAR99 |
| HTS Code | 8542.39.00.01 |
| Input Voltage Absolute-Max | 35 |
| Input Voltage-Max | 27 |
| Input Voltage-Min | 14.5 |
| JEDEC Package Code | R-PSSO-F3 |
| Length | 4.5 |
| Line Regulation-Max | 0.3 |
| Load Regulation-Max | 0.15 |
| Military Spec | False |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 3 |
| Operating Temperature TJ-Max | 150 |
| Output Current1-Max | 0.07 |
| Output Voltage1-Max | 12.6 |
| Output Voltage1-Min | 11.4 |
| Output Voltage1-Nom | 12 |
| Pin Count | 3 |
| REACH | Compliant |
| RoHS | Yes |
| Terminal Position | SINGLE |
| Voltage Tolerance-Max | 5 |
| Width | 2.5 |
