3566
30A Fuse Clip, Brass, Tin Plated, Through Hole PC Pin, 250V
Similar Components
3524
Fuseholder; 3AG Fuses; 3000 VDC; Panel Mount; UL Listed
3552
Radial Fuse Holder, 5A, 250V, Illuminated, PCB Mount
3561
CLIP FUSE 2AG/5MM SMD W/HOLE 10A
3537
Fuse Holder
3549-2
Illuminated Fuse Holder, 15A, 500V, Mini ATO/ATC, PCB Mount
3512P
5mm Dia Brass Fuse 15A Through Hole
About 3566
The Keystone Electronics 3566 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 30A Fuse Clip, Brass, Tin Plated, Through Hole PC Pin, 250V. Key parameters include Body Material: Brass, Contact Material: Brass, Contact Plating: Tin, Current Rating: 30A, and DC Rated Voltage: 250V. 3566 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 3566 specifications
Click to ask a quick question:
Parameters
| Body Material | Brass |
| Contact Material | Brass |
| Contact Plating | Tin |
| Current Rating | 30A |
| DC Rated Voltage | 250V |
| Fuse Current | 30A |
| Fuse Size | 13/32" Dia (10.3mm) |
| Lead Free | Lead Free |
| Material | Brass, Tin |
| Mount | Horizontal, PCB, Through Hole |
| Number of Circuits | 1 |
| Orientation | Horizontal |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Not Compliant |
| Termination | PC Pin |
