015500
System on Module (SOM) featuring an Intel Pentium processor and 8GB DDR3L system memory operating at 1867MHz. Supports Linux, Linux Yocto, Windows 10, Windows 10 IoT Core, and Windows 10 IoT Enterprise. Integrated Intel Gen 9 graphics deliver resolutions up to 4096x2160@DP, with multiple display interfaces including DP, eDP, HDMI, LVDS, and MIPI-CSI. Connectivity includes Intel I211 Gigabit Ethernet, 2 SATA ports, 6 USB ports, 1 SPI, 1 CAN, 1 I2C, and 1 UART.
Similar Components
DRV8833
10.8-V, 1-A dual H-bridge motor driver with current regulation 16-WQFN -40 to 85
BC847C
NEXPERIA - BC847C. - TRANSISTOR, NPN SOT-23
LM567CM/NOPB
Tone Decoder IC, 0.5MHz, 4.75-9V, SOIC
SMCJ26A
Uni-directional surface mount TVS diode, 1.5 kW peak pulse power, 26V DC rated voltage, and 42.1V clamping voltage. Features a DO-214AB package with a 35.7A peak pulse current rating and 6.5W max power dissipation. Operates across a -65°C to 150°C temperature range with 1µA leakage current. RoHS compliant and lead-free.
74HC541D
DRIVER
BK/HHD
This Eaton BK/HHD fuse is a 32V, 24A rated component with a 60V voltage rating. It features illuminated leads and is constructed from lead-free materials. The fuse is designed for free hanging applications and is available in bulk packaging with 100 units per package. The BK/HHD series is a general-purpose fuse suitable for a variety of applications.
About 015500
The Congatec 015500 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: System on Module (SOM) featuring an Intel Pentium processor and 8GB DDR3L system memory operating at 1867MHz. Supports Linux, Linux Yocto, Windows 10, Windows 10 IoT Core, and Windows 10 IoT Enterprise. Integrated Intel Gen 9 graphics deliver resolutions up to 4096x2160@DP, with multiple display interfaces including DP, eDP, HDMI, LVDS, and MIPI-CSI. Connectivity includes Intel I211 Gigabit Ethernet, 2 SATA ports, 6 USB ports, 1 SPI, 1 CAN, 1 I2C, and 1 UART.. Key parameters include Audio Interfaces: 0, BIOS: AMI Aptio UEFI 8MB, CAN: 1, Chipset Type: Integrated in SoC, and Display Chipset Type: Intel Gen 9. 015500 is manufactured by Congatec as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Congatec
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 015500 specifications
Click to ask a quick question:
Parameters
| Audio Interfaces | 0 |
| BIOS | AMI Aptio UEFI 8MB |
| CAN | 1 |
| Chipset Type | Integrated in SoC |
| Display Chipset Type | Intel Gen 9 |
| Display Interface | DP|eDP|HDMI|LVDS|MIPI-CSI |
| Display Type | LCD |
| Ethernet Controller Type | Intel I211 |
| Ethernet Speed | 1000Mbps |
| GPIO | 0 |
| Graphic Card Resolution | 1920x1200@LVDS|3840×2160@eDP|3840×2160@HDMI|4096×2160@DP |
| I2C | 1 |
| JTAG Support | No |
| Linux | Linux|Linux Yocto |
| Number of System Memory | 2 |
| Operating Systems | Linux|Linux Yocto|Win 10|Win 10 IoT Core|Win 10 IoT Enterprise |
| PATA | 0 |
| PCI | 0 |
| Processor Family | Pentium |
| Processor Type | Intel |
| RS232 | 0 |
| RS422 | 0 |
| RS485 | 0 |
| SATA | 2 |
| SPI | 1 |
| System Memory Maximum Size | 8G |
| System Memory Speed | 1867MHz |
| System Memory Type | DDR3L |
| UART | 1 |
| USART | 0 |
| USB | 6 |
| VGA | 0 |
| Video In | No |
| Windows | Win 10|Win 10 IoT Core|Win 10 IoT Enterprise |
