The Congatec 048100 Embedded Computers datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Intel Atom Quad Core 2GHz SBC Motherboard, 8GB LPDDR4, 2x GbE. Key parameters include AGP: 0, BIOS: AMI Aptio, Chipset Type: Integrated in SoC, Display Chipset Type: Intel Gen 9 HD, and Display Type: CRT|LCD. 048100 is manufactured by Congatec as part of their Embedded Computers product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.

Specifications

Manufacturer: Congatec
Category: Embedded Computers

Ask AI Assistant

Ask questions about 048100 specifications

AI Powered

Click to ask a quick question:

Parameters

AGP	0
BIOS	AMI Aptio
Chipset Type	Integrated in SoC
Display Chipset Type	Intel Gen 9 HD
Display Type	CRT\|LCD
Ethernet Card Number of Connectors	2
Ethernet Controller Type	Intel I211
Ethernet Speed	10Mbps/100Mbps/1000Mbps
Graphic Card Resolution	1920x1200@DP++\|1920x1200@LVDS\|4096x2160@eDP
Max Operating Temperature	60
Min Operating Temperature	0
Number of System Memory	4
On Board Ethernet Card	Yes
On Board Graphic Card	Yes
On Board Sound Card Type	Cirrus Logic CS4207
Operating Systems	Android\|Linux\|Win 10\|Win 10 IoT Core\|Win 10 IoT Enterprise
PATA	0
PCI	0
Processor Cores	Quad Core
Processor Family	Atom
Processor Number	x7-E3950
Processor Speed	2GHz
Processor Type	Intel
Product Depth	72
Product Length	100
RoHS	Yes
RoHS Version	2002/95/EC
SATA	1
Slot Support	No
System Memory Maximum Size	8GB
System Memory Speed	2400M
System Memory Type	LPDDR4
Type	Industrial Motherboard
USB	5
