W-1
Fuse Plug Fast Acting 1A 125V Threaded Socket Plug 30.18 X 34.93mm Box CE/UL
Similar Components
LKN-250
250V 250A Stud Mount Fuse
HM60200-2CR
600V 200A Surface Mount DIN Rail Fuse
MDL-15-R
Electric Fuse, Time Lag Blow, 15A, 1000A (IR),
BK/S-8202-2
2-Pole 300V 5A Bolt-Mount Fuse
400LMMT
Fuse 400A 240V Bolt 31 X 38 X 83mm Carton UL
GMA-1A
Electric Fuse, Fast Blow, 1A, 250VAC, 100A (IR), Through Hole, 5x20mm,
About W-1
The Eaton W-1 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Fuse Plug Fast Acting 1A 125V Threaded Socket Plug 30.18 X 34.93mm Box CE/UL. Key parameters include Current Rating: 1A, Fuse Size: 1.188 X 1.375in, Max Voltage Rating (AC): 125V, Package Quantity: 4, and Packaging: Bulk. W-1 is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about W-1 specifications
Click to ask a quick question:
Parameters
| Current Rating | 1A |
| Fuse Size | 1.188 X 1.375in |
| Max Voltage Rating (AC) | 125V |
| Package Quantity | 4 |
| Packaging | Bulk |
| RoHS | Not Compliant |
| Termination | Stud |
| Voltage Rating (AC) | 125V |
| Weight | 0.768oz |
