UPGNF66-1-72-802
Circuit Breaker Magnetic 2Pole 8A
Similar Components
209-3-1-63-3-4M-30-A
Circuit Breaker Magnetic 3Pole 30A 240VAC
AP7-1-61-702
240VAC Hydraulic Magnetic Relay, Panel Mount, 7A, 0.07s to 0.7s Trip Time
AP12-1-61-402
Hydraulic Magnetic Circuit Breaker, 240VAC, 4A, Panel Mount, -40 to 100°C
7851-26-30-I
Circuit Breaker Thermal 30A 120VAC
UPL1-1REC4-62-423
Circuit Breaker Magnetic 1Pole
209-1-1-62-4-9-60-A-V
240VAC Hydraulic Magnetic Relay, 60A, 2s to 18s Trip Time, Panel Mount
About UPGNF66-1-72-802
The Sensata UPGNF66-1-72-802 Hardware datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Circuit Breaker Magnetic 2Pole 8A. Key parameters include Actuator Type: Handle, AEC Qualified: No, Automotive: No, Cage Code: 82647, and Current Rating: 8. UPGNF66-1-72-802 is manufactured by Sensata as part of their Hardware product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Sensata
- Category
- Hardware
Ask AI Assistant
Ask questions about UPGNF66-1-72-802 specifications
Click to ask a quick question:
Parameters
| Actuator Type | Handle |
| AEC Qualified | No |
| Automotive | No |
| Cage Code | 82647 |
| Current Rating | 8 |
| ECCN | EAR99 |
| EU RoHS | Yes with Exemption |
| HTS Code | 8536200020 |
| Max Operating Temperature | 85 |
| Min Operating Temperature | -40 |
| Mounting | Panel Mount |
| Number of Poles | 2 |
| Number of Terminals | 4 |
| PPAP | No |
| Radiation Hardening | No |
| RoHS Versions | 2011/65/EU |
| Schedule B | 8536200020 |
| Terminal Design | Screw |
| Trip Time | 1.3s to 20s |
| Type | Hydraulic Magnetic |
