SRV05-4A
SRV05-4A is an 8-diode low capacitance steering diode array designed to protect high-speed data lines from overvoltage caused by ESD, EFT, and lightning. Each line is protected by steering transients to either the power supply rail or ground, featuring a dedicated common-anode TVS diode for additional clamping protection.
Similar Components
ADS1115IRUGT
16-Bit 4-Ch Delta-Sigma ADC, 860SPS, I2C, QFN
BK/ATM-15
Electric Fuse, Fast Blow, 15A, 32VDC, 1000A (IR), Inline/holder, ROHS COMPLIANT
BZX84C4V7
BZX84C Series 350 mW 4.7 V 10 mA Surface Mount Zener Diode - SOT-23-3
BK/GBB-V-6-R
This 6A axial through hole fuse has a maximum voltage rating of 250V AC and 125V DC. It features a tin plated contact and is packaged in bulk quantities of 100. The fuse is not radiation hardened and is compliant with RoHS regulations. It has a diameter of 6.35mm and a length of 1.292 inches.
MMSZ5257B
Diode Zener Single 33V 5% 500mW 2-Pin SOD-123 T/R
SMAJ13CA
Bidirectional Transient Voltage Suppressor (TVS) diode designed for surface mount applications. Features a 13V reverse standoff voltage and a 400W peak pulse power rating. Offers a 15.9V maximum breakdown voltage and a 21.5V clamping voltage. Operates across a wide temperature range from -65°C to 150°C with a low leakage current of 1µA. Packaged in a DO-214AC (SMD/SMT) case, this component is RoHS compliant and halogen-free.
About SRV05-4A
The SMC SRV05-4A Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: SRV05-4A is an 8-diode low capacitance steering diode array designed to protect high-speed data lines from overvoltage caused by ESD, EFT, and lightning. Each line is protected by steering transients to either the power supply rail or ground, featuring a dedicated common-anode TVS diode for additional clamping protection.. Key parameters include Breakdown Voltage: 6, Capacitance (I/O to GND): 3, Clamping Voltage (max): 17.5, Esd Protection: IEC 61000-4-2 (Air) ±15kV, (Contact) ±8kV, and Number of Lines Protected: 4. SRV05-4A is manufactured by SMC as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- SMC
- Category
- Semiconductors
Ask AI Assistant
Ask questions about SRV05-4A specifications
Click to ask a quick question:
Parameters
| Breakdown Voltage | 6 |
| Capacitance (I/O to GND) | 3 |
| Clamping Voltage (max) | 17.5 |
| Esd Protection | IEC 61000-4-2 (Air) ±15kV, (Contact) ±8kV |
| Number of Lines Protected | 4 |
| Operating Temperature | -55 to +125 |
| Peak Pulse Power (tp=8/20us) | 300 |
| RoHS | Compliant |
| Working Peak Reverse Voltage | 5 |
