SD103AW
This SILICON rectifier diode features a maximum reverse voltage of 40V and a maximum power dissipation of 0.4W. It is a dual terminal device with a terminal position of DUAL. The diode element material is SILICON and the diode type is a RECTIFIER DIODE. The device is packaged in a R-PDSO-F2 package type and is suitable for use in general purpose rectification applications. The operating temperature range is up to 175 degrees Celsius.
Similar Components
MM1Z12B
Zener Diode,
SS-5F-8A-AP
Fuse Subminiature Fast Acting 8A 125V Radial 8.5 X 4.3 X 7.85mm Ammo PSE/cULus
S3MB
This is a general purpose rectifier diode with a maximum operating temperature of 150 degrees Celsius and a minimum operating temperature of -55 degrees Celsius. It has a dual terminal position and a pin count of 2. The diode element material is silicon and the diode type is a rectifier diode. It is designed to handle a maximum reverse voltage of 1000 volts.
AO3415A
N-channel MOSFET transistor in a TO-236-3 package, designed for surface mounting. Features a continuous drain current of 5A and a drain-to-source voltage of 20V. Offers a low on-resistance of 45mΩ maximum. Operates across a wide temperature range from -55°C to 150°C with a maximum power dissipation of 1.5W. This component is RoHS compliant and lead-free.
BZT52C20
MULTICOMP - BZT52C20. - Zener Single Diode, BZT52C Series, 20 V, 410 mW, SOD-123, 2 Pins, 150 °C
US1A
Ultrafast Recovery Rectifier , DO-214AC/SMA, 50V, 1.00A, 50ns
About SD103AW
The TAK Cheong Electronics (Holdings) SD103AW Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: This SILICON rectifier diode features a maximum reverse voltage of 40V and a maximum power dissipation of 0.4W. It is a dual terminal device with a terminal position of DUAL. The diode element material is SILICON and the diode type is a RECTIFIER DIODE. The device is packaged in a R-PDSO-F2 package type and is suitable for use in general purpose rectification applications. The operating temperature range is up to 175 degrees Celsius.. Key parameters include Diode Element Material: SILICON, Diode Type: RECTIFIER DIODE, Eccn Code: EAR99, HTS Code: 8541.10.00.70, and Max Operating Temperature: 175. SD103AW is manufactured by TAK Cheong Electronics (Holdings) as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- TAK Cheong Electronics (Holdings)
- Category
- Semiconductors
Ask AI Assistant
Ask questions about SD103AW specifications
Click to ask a quick question:
Parameters
| Diode Element Material | SILICON |
| Diode Type | RECTIFIER DIODE |
| Eccn Code | EAR99 |
| HTS Code | 8541.10.00.70 |
| Max Operating Temperature | 175 |
| Military Spec | False |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Pin Count | 2 |
| Power Dissipation-Max | 0.4 |
| REACH | Compliant |
| Rep Pk Reverse Voltage-Max | 40 |
| Terminal Position | DUAL |
