PSA3605
Spectrum Analyser 3.6 GHz, PSA3605, Aim-TTi
Similar Components
PSA U02
AIM-TTI INSTRUMENTS PSA U02 FIRMWARE UPGRADE, SPECTRUM ANALYSER
PSA1302
Handheld Spectrum Analyzer, 1.3GHz Bandwidth, 1MHz to 1.3GHz
PSA2-SC
AIM-TTI INSTRUMENTS PSA2-SC CASE, SOFT, TRANSIT, PSA S2
PSA6005
Handheld Spectrum Analyzer 10MHz 6GHz 1.8GB USB
TGR1040
Signal generator, 1 GHz, TGR1040, Aim-TTi
RM415
AIM-TTI INSTRUMENTS RM415 BLANKING PLATE, 1/3\
About PSA3605
The Aim-Tti PSA3605 Test Equipment datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Spectrum Analyser 3.6 GHz, PSA3605, Aim-TTi. Key parameters include Bandwidth: 300Hz, Battery Type: LITHIUM-ION, Display Type: LCD, Frequency Stability: 1ppm, and Height: 192mm. PSA3605 is manufactured by Aim-Tti as part of their Test Equipment product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Aim-Tti
- Category
- Test Equipment
Ask AI Assistant
Ask questions about PSA3605 specifications
Click to ask a quick question:
Parameters
| Bandwidth | 300Hz |
| Battery Type | LITHIUM-ION |
| Display Type | LCD |
| Frequency Stability | 1ppm |
| Height | 192mm |
| Interface | USB |
| Length | 49mm |
| Max Frequency | 3.6GHz |
| Max Operating Temperature | 40°C |
| Memory Size | 1.8GB |
| Min Frequency | 10MHz |
| Min Operating Temperature | -5°C |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Series | PSA 5 |
| Test Frequency | 10MHz |
| Type | Handheld |
| Weight | 560g |
| Width | 92mm |
