MQ-3
The BEL MQ 3 micro fuse is a fast acting axial lead fuse rated for 125V and 3A. It has a typical melting I2t of 1.1 and a typical cold resistance of 0.028 ohms. The fuse operates within a temperature range of -55 to 125 degrees Celsius. It is designed for general use in circuit protection applications.
Similar Components
AHT20
Digital humidity and temperature sensor combines a MEMS capacitive humidity element, an on-chip temperature sensor, and calibrated digital output. The device operates from a 2.2 V to 5.5 V supply and communicates over a standard I2C interface at address 0x38. It measures 0% to 100% RH with typical ±2% RH accuracy and -40 °C to 85 °C with typical ±0.3 °C temperature accuracy. The two-row SMD package has a 3 mm by 3 mm footprint and 1.0 mm height for reflow soldering.
LIS3DHHTR
Triple-axis accelerometer with selectable full scales of ±2.5g. Features a wide operating temperature range from -40°C to 85°C, suitable for industrial applications. This 16-terminal component operates from a 1.71V to 3.6V supply. Packaged in a compact 5x5mm S-XBGA-N16 (CCLGA) with bottom-terminated terminals.
LIS2DH12TR
MEMS digital output motion sensor: ultra-low-power high-performance 3-axis "femto" accelerometer
BMP180
The Bosch BMP180 is a pressure sensor with an accuracy of 2%. It operates over a temperature range of -40°C to 85°C and features an I2C output. The device is packaged in a lead-free LGA package and is suitable for board mount applications.
TLE4905L
Hall Effect Sensor, 4mT Min, 17mT Max, Bipolar, Plastic/epoxy, Rectangular, 3 Pin, Through Hole Mount, GREEN, PLASTIC, SSOP-3
BH1750
Light to Digital Ambient Light Sensor Digital 3V 6-Pin WSOF T/R
About MQ-3
The BEL MQ-3 Sensors Transducers datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: The BEL MQ 3 micro fuse is a fast acting axial lead fuse rated for 125V and 3A. It has a typical melting I2t of 1.1 and a typical cold resistance of 0.028 ohms. The fuse operates within a temperature range of -55 to 125 degrees Celsius. It is designed for general use in circuit protection applications.. Key parameters include Acting: Fast, Current Rating: 3A, Max Operating Temperature: 125°C, Min Operating Temperature: -55°C, and Number of Terminals: 2. MQ-3 is manufactured by BEL as part of their Sensors Transducers product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- BEL
- Category
- Sensors Transducers
Ask AI Assistant
Ask questions about MQ-3 specifications
Click to ask a quick question:
Parameters
| Acting | Fast |
| Current Rating | 3A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Number of Terminals | 2 |
| RoHS | Yes with Exemption |
| RoHS Version | 2011/65/EU |
| Termination Style | Axial |
| Type | Micro |
| Typical Cold Resistance | 0.028Ohm |
| Typical Melting I2t | 1.1A²s |
| Voltage Rating | 125V |
