JLE-1-1-53-3-B4-175
Circuit Breaker Magnetic 1Pole 175A 160VDC
Similar Components
JLE-1-1REC4-52F-1-B4-200
65VDC 200mA Panel Mount Magnetic Toggle Switch
205-11-1-65-4-303-0
Circuit Breaker Magnetic 2Pole 30A 250VAC
219-3-1-65-7-9-85-A
Circuit Breaker Magnetic 3Pole 85A 600VAC
APL1-1-52-302-A
Circuit Breaker Magnetic 1Pole 65VDC
6766-19-70
Circuit Breaker Thermal 70A 30VDC
APL111-1-62F-203
Circuit Breaker Magnetic 3Pole 20A
About JLE-1-1-53-3-B4-175
The Sensata JLE-1-1-53-3-B4-175 Hardware datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Circuit Breaker Magnetic 1Pole 175A 160VDC. Key parameters include Actuator Type: Toggle, AEC Qualified: No, Automotive: No, Cage Code: 82647, and Current Rating: 175. JLE-1-1-53-3-B4-175 is manufactured by Sensata as part of their Hardware product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Sensata
- Category
- Hardware
Ask AI Assistant
Ask questions about JLE-1-1-53-3-B4-175 specifications
Click to ask a quick question:
Parameters
| Actuator Type | Toggle |
| AEC Qualified | No |
| Automotive | No |
| Cage Code | 82647 |
| Current Rating | 175 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| HTS Code | 8536200020 |
| Max Operating Temperature | 85 |
| Min Operating Temperature | -40 |
| Mounting | Panel Mount |
| Number of Poles | 1 |
| Number of Terminals | 2 |
| PPAP | No |
| Radiation Hardening | No |
| RoHS Versions | 2011/65/EU, 2015/863 |
| Schedule B | 8536200020 |
| Terminal Design | Stud |
| Trip Time | 22s to 150s |
| Type | Hydraulic Magnetic |
| Voltage Rating | 160VDC |
