HTB-56I-R
HTB-56I-R 250V 20A Panel Mount Fuse
Similar Components
LPJ-200SP
200A 600V Class J Slow-Blow Fuse, Bolt Tap, 1.63x3in
DFJ-12
12A Holder Mount Fuse, 450V DC, 600V AC, UL, CSA, CE
BK1/S501-10-R
Surface Mount Fuse Holder, 10A, 250V AC, Nickel Plated
TPS-30
30A 170V DC Electrical Fuse Holder
BK/GDC-5A
5A Surface Mount Fuse Holder, 250V AC, 5 x 20mm
T30030-2SR
Fuse Block 30A 300V Lug Screw Mount
About HTB-56I-R
The Eaton HTB-56I-R Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: HTB-56I-R 250V 20A Panel Mount Fuse. Key parameters include Body Material: Thermoplastic, Color: Black, Contact Material: Brass, Tin, Current Rating: 20A, and Fuse Size: 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm). HTB-56I-R is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about HTB-56I-R specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Contact Material | Brass, Tin |
| Current Rating | 20A |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Series | HTB |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Weight | 0.4oz |
