HTB-36I-R
HTB-36I-R 250V 20A Panel Mount Fuse
Similar Components
LPN-RK-200SP
200A 250V DC Rated Fuse
BK/HLD
250V 15A Panel Mount Fuse, Illuminated, GBA/GLD, 100-Count
BK/HTB-24M
16A 250V Fuse Holder, Panel Mount, Quick Connect, Illuminated
BG3012SQ
Chassis Mount Fuse, 600V, 15A, SC, Illuminated, 2-Pole, 2-Circuit
HVA-2-NR
Buss High Voltage Fuses
BK/HTB-56I-R
Panel Mount Fuse 20A 250V 1/4\
About HTB-36I-R
The Eaton HTB-36I-R Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: HTB-36I-R 250V 20A Panel Mount Fuse. Key parameters include Body Material: Thermoplastic, Color: Black, Contact Material: Brass, Tin, Current Rating: 20A, and Fuse Size: 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm). HTB-36I-R is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about HTB-36I-R specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Contact Material | Brass, Tin |
| Current Rating | 20A |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Length | 46.8mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Series | HTB |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Weight | 0.352oz |
