HKP-HH-R
The HKP-HH-R is a 250V panel mount fuse with a current rating of 15A. It is constructed from thermoset material and features a brass and tin contact plating. The fuse is available in a bulk packaging quantity of 10. The HKP-HH-R operates within a standard temperature range and does not undergo radiation hardening.
Similar Components
FNQ-R-5
The Eaton FNQ-R-5 is a 600V 5A surface mount fuse holder from the CC-TRON FNQ-R series. It features a time delay blow characteristic and meets UL, CSA, and CE approvals. The holder is designed for surface mount applications and is available in a bulk packaging quantity of 10. The FNQ-R-5 has a diameter of 10.3mm and a length of 38.1mm, with a fuse size of 13/32 X 1-1/2in. It is lead free and compliant with radiation hardening requirements.
FWH-50B
Fuse 50A 500V Bolt Tap 20.65 X 40.46mm Carton CSA/UL
KTN-R-20
The Eaton KTN-R-20 is a 20A surface mount MELF fuse with a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It has a maximum voltage rating of 250V AC and is available in a bulk packaging quantity of 10. The fuse is 2 inches in length and has a diameter of 0.56 inch, with a weight of 0.768 ounces. It is designed for use in circuit protection applications.
BK/GBB-1-R
Very fast blow electric fuse, 1A current rating, 250VAC and 125VDC voltage ratings. Features a 200A interrupting rating, 6.3mm x 32mm fuse size, and 177.5mR DC cold resistance. Nickel plated contacts and clip termination for holder mounting. RoHS compliant with CSA and UR approvals.
KAC-80
The Eaton KAC-80 fuse is a 600V, 80A electrical fuse with a bolt mount and a diameter of 1inch. It has a length of 2.75inch and a body height of 69.85mm. The fuse is available in a bulk packaging with 5 units per package. It is not RoHS compliant.
BK/ATM-30
This 30A 32V lead free blade fuse holder is designed for use with fuses of size 10.92 X 3.81 X 8.81mm. It has a depth of 3.81mm and a height of 0.347inch. The holder is packaged in bulk with 500 units per package. It is compliant with ROHS standards and has a weight of 0.016oz.
About HKP-HH-R
The Eaton HKP-HH-R Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: The HKP-HH-R is a 250V panel mount fuse with a current rating of 15A. It is constructed from thermoset material and features a brass and tin contact plating. The fuse is available in a bulk packaging quantity of 10. The HKP-HH-R operates within a standard temperature range and does not undergo radiation hardening.. Key parameters include Body Material: Thermoset, Color: Black, Contact Material: Brass, Tin, Contact Plating: Tin, and Current Rating: 15A. HKP-HH-R is manufactured by Eaton as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Semiconductors
Ask AI Assistant
Ask questions about HKP-HH-R specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoset |
| Color | Black |
| Contact Material | Brass, Tin |
| Contact Plating | Tin |
| Current Rating | 15A |
| Depth | 20.07mm |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Material | Brass, Tin |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| RS Americas | —10$14.3———EachView offer |
| RS UK | 7,73010$13.9686$12.7382$12.3618$12.0124PackView offer |
| Series | HKP |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Weight | 0.56oz |
