HC-05
Inductor High Current Toroid 19uH 6% 50A 0.0016Ohm DCR RDL
Similar Components
SI4432-B1-FM
RF Transceiver 240-930MHz, 256Kbps, SPI, 20dBm, QFN
SX1262IMLTRT
LoRaWAN and FSK RF transceiver IC, operating across a wide frequency range with excellent sensitivity and low power consumption. Features configurable modulation schemes, including LoRa, FSK, GFSK, MSK, OOK, and BPSK, enabling flexible wireless communication. Integrated power amplifier and low-noise amplifier provide robust signal transmission and reception. Supports a broad supply voltage range of 2.5V to 3.3V, making it suitable for various battery-powered applications. Packaged in a 24-pin QFN EP for compact integration.
ESP32-C3-FH4
Low-power Wi-Fi and Bluetooth Low Energy microcontroller SoC integrates a 32-bit single-core RISC-V processor running up to 160 MHz. The device supports 2.4 GHz IEEE 802.11b/g/n Wi-Fi with 20 MHz and 40 MHz bandwidth and Bluetooth 5 LE data rates from 125 Kbps to 2 Mbps. On-chip resources include 400 KB SRAM, 384 KB ROM, 8 KB RTC SRAM, 4096-bit eFuse memory, security accelerators, and 22 configurable GPIOs. The base chip is supplied in a 32-pin 5 mm by 5 mm QFN package and operates from 3.0 V to 3.6 V over a -40 °C to 105 °C ambient range.
SX1278IMLTRT
Telecom IC, 3.3V, 28-Pin QFN, Industrial Temp
CC1101
RF and Wireless IC for cellular applications, featuring a 300MHz to 928MHz frequency range and a maximum data rate of 600Kbps. This surface mount component offers a sensitivity of -116dBm and a maximum output power of 10dBm. Operating with a supply voltage between 1.8V and 3.6V, it utilizes an SPI interface and consumes 17.1mA during receiving and 34.2mA during transmitting. The VQFN package measures 4mm x 4mm x 0.85mm and operates within a temperature range of -40°C to 85°C.
CC2500
Specialty telecom circuit featuring a 2.4GHz frequency range with a bandwidth up to 2.4835GHz. Supports data rates of 500Kbps and offers multiple modulation schemes including 2-FSK, ASK, GFSK, MSK, and OOK. Operates with an SPI interface, a supply voltage range of 1.8V to 3.6V, and a sensitivity of -104dBm. Packaged in a 4x4mm VQFN EP with gold contact plating, this surface mount component is RoHS compliant.
About HC-05
The Talema Group HC-05 Rf Wireless datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Inductor High Current Toroid 19uH 6% 50A 0.0016Ohm DCR RDL. Key parameters include Height: 38mm, Inductance: 19uH, Lead Style: Radial, Max DC Resistance: 0.0016(Typ)Ohm, and Maximum DC Current: 50A. HC-05 is manufactured by Talema Group as part of their Rf Wireless product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Talema Group
- Category
- Rf Wireless
Ask AI Assistant
Ask questions about HC-05 specifications
Click to ask a quick question:
Parameters
| Height | 38mm |
| Inductance | 19uH |
| Lead Style | Radial |
| Max DC Resistance | 0.0016(Typ)Ohm |
| Maximum DC Current | 50A |
| Product Depth | 56.5mm |
| Product Length | 58mm |
| RoHS | Yes |
| RoHS Version | 2011/65/EU, 2015/863 |
| Technology | Toroid |
| Tolerance | 6% |
| Type | High Current |
