BK/HTB-96M
HTB-96M 250V 20A Panel Mount Fuse
Similar Components
FRN-R-3
Fusetron FRN-R 3A 250V Time Delay Fuse
MDL-7/10-R
250V 700mA General Purpose Fuse Holder
F02A32V20A
Fuse Miniature 20A 32V Holder Cartridge 6.35 X 31.75mm
HTB-26I-R
FUSEHLDR 250V 3AG INLINE PNL MNT
ANN-300
Fuse Limiter Very Fast Acting 300A 125V Stud Mount Lug 22.35 X 81.03mm CE/UL
LPJ-10SP
10A 600V Time Delay Fuse, Class J, Cartridge, UL/CSA/CE
About BK/HTB-96M
The Eaton BK/HTB-96M Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: HTB-96M 250V 20A Panel Mount Fuse. Key parameters include Body Material: Thermoplastic, Color: Black, Current Rating: 20A, DC Rated Voltage: 250V, and Fuse Size: 5mm x 20mm. BK/HTB-96M is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about BK/HTB-96M specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Current Rating | 20A |
| DC Rated Voltage | 250V |
| Fuse Size | 5mm x 20mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Poles | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Series | HTB |
| Termination | Solder |
| Voltage Rating | 250V |
| Weight | 0.352oz |
