BK/HTB-36I
20A 250V Illuminated Fuse Holder, Panel Mount, Quick Connect
Similar Components
GDA-1A
5 x 20mm 1A 250V Ceramic Clip Termination Fuse
KLM-2-1/2
KLM Series 600V 2.5A Melf Fuse
LPN-RK-100SP
Fuse Class RK1 Slow Blow Acting 100A 250V Holder Clip Carton CE/CSA/UL
TCFH60N
600V 60A DIN Rail Fuse, Illuminated, Lead Free, -40°C to 80°C
JM60400-2MW16
Fuse Block 400A 600VAC DIN Rail Screw
JJN-125
Limitron JJN 160V 125A Bolt-Style Fuse
About BK/HTB-36I
The Eaton BK/HTB-36I Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 20A 250V Illuminated Fuse Holder, Panel Mount, Quick Connect. Key parameters include Body Material: Thermoplastic, Color: Black, Current Rating: 20A, DC Rated Voltage: 250V, and Fuse Current: 20A. BK/HTB-36I is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about BK/HTB-36I specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Current Rating | 20A |
| DC Rated Voltage | 250V |
| Fuse Current | 20A |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 46.8mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS | Compliant |
| Series | HTB |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 250V |
| Weight | 0.32oz |
