BK/HTB-34M
16A 250V Fuse Holder, Panel Mount, Quick Connect, Illuminated
Similar Components
GLN-3/10
Radial Fuse 300mA 125V 3.7x7.6mm Through Hole
HHL
FUSE HLDR BLADE 32V 16A IN LINE
HKP-1K0463
Fuse Holder
SS-5H-5A-BK
5A Time Delay Fuse, 250V, Radial, Plastic, Bulk
BK/AGC-V-12-R
12A Axial Through Hole Fuse, 32V, Lead Free, RoHS Compliant
TPS-50V
Fuse 50A 170V Holder 14.22 X 44.7mm Glass Melamine CE/UL
About BK/HTB-34M
The Eaton BK/HTB-34M Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 16A 250V Fuse Holder, Panel Mount, Quick Connect, Illuminated. Key parameters include Body Material: Thermoplastic, Color: Black, Contact Material: Brass, Contact Plating: Tin, and Current Rating: 16A. BK/HTB-34M is manufactured by Eaton as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Eaton
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about BK/HTB-34M specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Tin |
| Current Rating | 16A |
| DC Rated Voltage | 250V |
| Flammability Rating | UL94 V-0 |
| Fuse Size | 5mm x 20mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 46.8mm |
| Material | Thermoplastic |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Series | HTB |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Weight | 0.32oz |
