74HC02
Die Gate Nor Quad 2INPUT
Similar Components
SI2302DS
Power Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET
TDA1521
Audio Amplifier, 2 Func, Bipolar,
FNM-8/10
The Eaton FNM-8/10 fuse holder is a fiberglass-bodied component with a current rating of 800mA and a maximum voltage rating of 250V AC. It is available in a bulk packaging configuration with 10 units per package. The holder is designed for use with 13/32 X 1-1/2in fuses and features a clip termination. The FNM-8/10 is compliant with RoHS regulations and has approvals from UL, CSA, and CE.
ULN2003A
Seven-channel NPN Darlington transistor array, DIP package, designed for through-hole mounting. Features a collector-emitter breakdown voltage of 50V, maximum collector current of 500mA per channel, and a collector-emitter saturation voltage of 1.1V. Operates within a temperature range of -40°C to 85°C with a maximum power dissipation of 2.25W. RoHS compliant and lead-free.
MMBT2222A
NPN bipolar junction transistor (BJT) for surface mount applications. Features a 40V collector-emitter voltage, 1A maximum DC collector current, and 350mW maximum power dissipation. This single-element transistor is housed in a 3-pin SOT-23 (TO-236AB) plastic package with gull-wing leads. Operating temperature range is -55°C to 150°C, with a minimum transition frequency of 300MHz.
P6SMB7.5A
Uni-directional TVS diode for circuit protection, featuring a 600W peak pulse power dissipation. This single-element device offers a maximum reverse stand-off voltage of 64.1V and a maximum clamping voltage of 103V. Housed in a 2-pin SMB (DO-214AA) surface-mount plastic package with J-lead configuration, it operates across a wide temperature range of -65°C to 150°C.
About 74HC02
The Philips 74HC02 Semiconductors datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Die Gate Nor Quad 2INPUT. Key parameters include Logic Function: NOR GATE and RoHS: Not Compliant. 74HC02 is manufactured by Philips as part of their Semiconductors product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Philips
- Category
- Semiconductors
Ask AI Assistant
Ask questions about 74HC02 specifications
Click to ask a quick question:
Parameters
| Logic Function | NOR GATE |
| RoHS | Not Compliant |
