5682-0
Test Plugs u0026 Test Jacks TIP ADAPTER BLACK
Similar Components
1743-12-0
Test Leads SPADE LUG PATCH CO
3289-2
Red 150V 5A Lead Free Test Probe
5643
Test Clips TEST CLIP 100 PIN
6317-96
PLUGS WE310 Y/9-PIN MALE CABLE
5645L-2
Test Clips TEST CLIP 160 PIN
3785-24-2
Test Leads MINI GRABBER TEST
About 5682-0
The Pomona Electronics 5682-0 Test Accessories datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Test Plugs u0026 Test Jacks TIP ADAPTER BLACK. Key parameters include Body Material: Nylon, Color: Black, Red, Contact Material: Stainless Steel, Current Rating: 3A, and Housing Color: Black. 5682-0 is manufactured by Pomona Electronics as part of their Test Accessories product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Pomona Electronics
- Category
- Test Accessories
Ask AI Assistant
Ask questions about 5682-0 specifications
Click to ask a quick question:
Parameters
| Body Material | Nylon |
| Color | Black, Red |
| Contact Material | Stainless Steel |
| Current Rating | 3A |
| Housing Color | Black |
| Lead Free | Lead Free |
| Length | 3.27inch |
| Max Current Rating | 3A |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | 122°C |
| Mount | Cable |
| Number of Contacts | 1 |
| Number of Ports | 1 |
| Orientation | Straight |
| Package Quantity | 5 |
| RoHS | Not Compliant |
| RoHS Compliant | No |
| Series | 5682 |
