About 5305
The Pomona Electronics 5305 Test Accessories datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: BNC to SMD Test Leads, 150V, 22AWG PVC. Key parameters include Body Material: Brass, Stainless Steel, Color: Black, Red, Connector Type A: BNC, Connector Type B: SMD/SMT, Clip, and Contact Material: Copper. 5305 is manufactured by Pomona Electronics as part of their Test Accessories product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Pomona Electronics
- Category
- Test Accessories
Ask AI Assistant
Ask questions about 5305 specifications
Click to ask a quick question:
Parameters
| Body Material | Brass, Stainless Steel |
| Color | Black, Red |
| Connector Type A | BNC |
| Connector Type B | SMD/SMT, Clip |
| Contact Material | Copper |
| Insulation Color | Black |
| Insulation Material | PVC |
| Lead Free | Lead Free |
| Lead Length | 140mm |
| Length | 218.8mm |
| Max Operating Temperature | 55°C |
| Max Voltage Rating (AC) | 150V |
| Min Operating Temperature | 131°C |
| Mount | Cable |
| Package/Case | SMD/SMT |
| Package Quantity | 5 |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| RoHS Compliant | Yes |
| Series | SMD Grabber® 5305 |
| Voltage Rating | 150V |
| Voltage Rating (AC) | 150V |
| Wire/Cable Diameter | 0.04inch |
| Wire/Cable Gauge | 22AWG |
| Wire/Cable Type | PVC |
