47-12-211-62
Screw Captive Knurled-HD Slot 6-32-THD Steel Zinc Chromate
Similar Components
09-13-602-11
Screw Captive Knurled-HD Slot 26.59mm-LG 1 3in/64in-LG 1.047in-LG Steel Zinc Chromate
12-11-603-11
Screw Captive Slot 28.2mm-LG 1 7in/64in-LG 1.11in-LG Low Carbon Steel Zinc Chromate
47-82-544-22
Captive Knurled Head Torx Drive Die Point Steel Screw
12-13-507-11
Low Carbon Steel Knurled Head Screw, 5.9mm Diameter, 25mm Length, Zinc Chromate Finish
51-23914-24
Standoffs Round F 13.08mm 10-24 Stainless Steel Passivated
09-13-404-14
Screw Captive Knurled-HD Slot 20.24mm-LG 51in/64in-LG 0.797in-LG Steel Zinc Chromate
About 47-12-211-62
The Southco 47-12-211-62 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Screw Captive Knurled-HD Slot 6-32-THD Steel Zinc Chromate. Key parameters include AEC Qualified: No, Automotive: No, Body Diameter (Imperial - Decimal) (in): 0.136, Body Diameter (Metric) (mm): 3.45, and Cage Code: 94222. 47-12-211-62 is manufactured by Southco as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Southco
- Category
- Fasteners
Ask AI Assistant
Ask questions about 47-12-211-62 specifications
Click to ask a quick question:
Parameters
| AEC Qualified | No |
| Automotive | No |
| Body Diameter (Imperial - Decimal) (in) | 0.136 |
| Body Diameter (Metric) (mm) | 3.45 |
| Cage Code | 94222 |
| Drive Type | Slot |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Finish | Zinc Chromate |
| Head Type | Knurled |
| Material | Steel |
| Point Type | Die |
| PPAP | No |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318159000 |
| Thread Length (Imperial - Decimal) (in) | 0.4 |
| Thread Length (Imperial) (in) | 13/32 |
| Thread Length (Metric) (mm) | 10.16 |
| Type | Captive |
