47-10-333-22
Screw Captive Knurled-HD Phillips 8-32-THD Steel Zinc Chromate
Similar Components
51-13-913-24
Stainless Steel Knurled Head Screw, 4.83mm Body Diameter, 6.35mm Head Height, Captive Type
47-10-334-62
Machine Screw, Self-Tapping, Phillips Drive, Knurled Head, 4.17mm Body Diameter
51-13-710-24
Screw Captive Knurled-HD Slot 10-24-THD Stainless Steel Passivated
12-13-203-11
Screw Captive Knurled-HD Slot 15.5mm-LG 39in/64in-LG 0.61in-LG Low Carbon Steel Zinc Chromate
47-91-541-62
Screw Captive Knurled-HD Torx M5 X 0.8-THD Steel Zinc Chromate
47-12-331-22
Captive Knurled Head Screw, 4.17mm Diameter, 10.16mm Length, Steel, Zinc Chromate Finish
About 47-10-333-22
The Southco 47-10-333-22 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Screw Captive Knurled-HD Phillips 8-32-THD Steel Zinc Chromate. Key parameters include AEC Qualified: No, Automotive: No, Body Diameter (Imperial - Decimal) (in): 0.164, Body Diameter (Metric) (mm): 4.17, and Cage Code: 94222. 47-10-333-22 is manufactured by Southco as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Southco
- Category
- Fasteners
Ask AI Assistant
Ask questions about 47-10-333-22 specifications
Click to ask a quick question:
Parameters
| AEC Qualified | No |
| Automotive | No |
| Body Diameter (Imperial - Decimal) (in) | 0.164 |
| Body Diameter (Metric) (mm) | 4.17 |
| Cage Code | 94222 |
| Drive Type | Phillips |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Finish | Zinc Chromate |
| Head Type | Knurled |
| Material | Steel |
| Point Type | Die |
| PPAP | No |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318159000 |
| Thread Length (Imperial - Decimal) (in) | 0.32 |
| Thread Length (Metric) (mm) | 8.13 |
| Type | Captive |
