4527
5A 250V PCB Fuse Holder, Horizontal, Illuminated, Nylon
Similar Components
3552
Radial Fuse Holder, 5A, 250V, Illuminated, PCB Mount
3522-3
30A 500V ATO/ATC Fuse, Brass, Tin, Vertical, Through Hole Mount
3540
Fuse Holder HIGH UL RTG FUSE HOLDER
3537
Fuse Holder
3529
1/4\
3519
10A Fuse Clip, Brass, Tin Plated, PCB Mount, 5mm Dia
About 4527
The Keystone Electronics 4527 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 5A 250V PCB Fuse Holder, Horizontal, Illuminated, Nylon. Key parameters include Approvals: UL, Body Material: Nylon, Color: Black, Contact Material: Brass, Tin, and Contact Plating: Tin. 4527 is manufactured by Keystone Electronics as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Keystone Electronics
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 4527 specifications
Click to ask a quick question:
Parameters
| Approvals | UL |
| Body Material | Nylon |
| Color | Black |
| Contact Material | Brass, Tin |
| Contact Plating | Tin |
| Current Rating | 5A |
| DC Rated Voltage | 250V |
| Flammability Rating | UL94 V-0 |
| Fuse Current | 5A |
| Fuse Size | 0.197 Dia x 0.787 L (5mm x 20mm) |
| Height | 10.8mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 24.2mm |
| Material | Brass, Tin |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Through Hole, Horizontal, PCB |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Orientation | Horizontal |
| Package Quantity | 100 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Termination | PC Pin |
| Voltage | 250V |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 250V |
| Width | 9.7mm |
