3GSPB10100
Self-Tapping Screw, Stainless Steel 18-8, 1/16 in, Die Point, Button Head
Similar Components
3GMKB10037#
Screw Machine Button-HD 10-24-THD 9.53mm-LG Stainless Steel 18-8
3GMKB06125#
Machine Screw, Stainless Steel 18-8, Button Head, Die Point, 1.25 in Body Length
3GMKB50200
Screw Machine Button-HD 1/2-13-THD 50.8mm-LG 2in-LG Stainless Steel 18-8
3GSAF12150
Self-Tapping Screw, Stainless Steel 18-8, 5.49mm Diameter, 38.1mm Length
93GMKB03006#
Stainless Steel Machine Screw 18-8, 1/8 in Dia, 15/64 in Length
93GMKF06035
Screw Machine Flat-HD M6 X 1-THD 35mm-LG Stainless Steel 18-8
About 3GSPB10100
The Bryce Fastener 3GSPB10100 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Self-Tapping Screw, Stainless Steel 18-8, 1/16 in, Die Point, Button Head. Key parameters include Body Diameter (Imperial - Decimal) (in): 0.19, Body Diameter (Imperial) (in): 3/16, Body Diameter (Metric) (mm): 4.83, Body Length (Imperial) (in): 1, and Body Length (Metric) (mm): 25.4. 3GSPB10100 is manufactured by Bryce Fastener as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Bryce Fastener
- Category
- Fasteners
Ask AI Assistant
Ask questions about 3GSPB10100 specifications
Click to ask a quick question:
Parameters
| Body Diameter (Imperial - Decimal) (in) | 0.19 |
| Body Diameter (Imperial) (in) | 3/16 |
| Body Diameter (Metric) (mm) | 4.83 |
| Body Length (Imperial) (in) | 1 |
| Body Length (Metric) (mm) | 25.4 |
| Cage Code | 3CJH1 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Head Type | Button |
| Material | Stainless Steel 18-8 |
| Point Type | Die |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318140000 |
| Thread Length (Imperial - Decimal) (in) | 1 |
| Thread Length (Imperial) (in) | 1 |
| Thread Length (Metric) (mm) | 25.4 |
| Type | Self Tapping |
