3GMPF11037
Machine Screw, 18-8 Stainless Steel, Flat Head, Die Point, 3/16 in Diameter
Similar Components
3GMAF31150
Machine Screw, Stainless Steel 18-8, 7.94mm Diameter, 38.1mm Length
3GMPF25050
Machine Screw, Stainless Steel 18-8, 6.35mm Diameter, 12.7mm Length
3GMKB04025
Screw Machine Button-HD 4-40-THD 6.35mm-LG Stainless Steel 18-8
3GMKF31300#
Screw Machine Flat-HD 5/16-18-THD 76.2mm-LG 3in-LG Stainless Steel 18-8
93GMPF06025
Machine Screw, Stainless Steel 18-8, 6mm Diameter, 25mm Length, Flat Head, Die Point
93GMAB03010
Screw Machine Button-HD M3 X 0.5-THD 10mm-LG Stainless Steel 18-8
About 3GMPF11037
The Bryce Fastener 3GMPF11037 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Machine Screw, 18-8 Stainless Steel, Flat Head, Die Point, 3/16 in Diameter. Key parameters include Body Diameter (Imperial - Decimal) (in): 0.19, Body Diameter (Imperial) (in): 3/16, Body Diameter (Metric) (mm): 4.83, Body Length (Imperial - Decimal) (in): 0.375, and Body Length (Metric) (mm): 9.53. 3GMPF11037 is manufactured by Bryce Fastener as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Bryce Fastener
- Category
- Fasteners
Ask AI Assistant
Ask questions about 3GMPF11037 specifications
Click to ask a quick question:
Parameters
| Body Diameter (Imperial - Decimal) (in) | 0.19 |
| Body Diameter (Imperial) (in) | 3/16 |
| Body Diameter (Metric) (mm) | 4.83 |
| Body Length (Imperial - Decimal) (in) | 0.375 |
| Body Length (Metric) (mm) | 9.53 |
| Cage Code | 3CJH1 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Head Type | Flat |
| Material | Stainless Steel 18-8 |
| Point Type | Die |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318159000 |
| Thread Length (Imperial - Decimal) (in) | 0.375 |
| Thread Length (Metric) (mm) | 9.53 |
| Type | Machine |
